Digital Output - Do1, Do2, Do3, Do4; Terminals; Electrical Specifications - Val Controls I 24-B Series Hardware Manual

Minimum use operating area
Cable length
Linearity
Temperature coefficient
AI10 – Loop
External loop max Rload
Operating area
Minimum span
Cable length
Linearity
Temperature coefficient
Rin
Digital output – DO1, DO2, DO3, DO4
3.5
24 VDC digital outputs.
DO
-
+
+ -

3.5.1 Terminals

DO1 13 (+)
14 (-)
DO2 16 (+)
17 (-)
DO3 19 (+)
20 (-)
DO4 22 (+)
23 (-)
All DOs (-) are common with PS2 (-)

3.5.2 Electrical specifications

DO – Digital outputs
Max load per digital output
Max load total
Val Controls A/S • Sallingsundvej 5 • DK-6715 Esbjerg N • Tel. +45 7547 0600
DHW-UM-001
Revision: 6
40%
1.5 meters
< 0.1%
0.01% / 1°C (Warm-up: 10 min)
820 Ohm at 20mA and 16.4VDC
4 – 20mA
12mA
1000 meters
< 0.1%
0.01% / 1°C (Warm-up: 10 min)
< 100 Ohm
up to 48W at 24VDC
up to 192W at 24VDC
vc@valcontrols.com • www.valcontrols.com
9/12
