GOLDEN IDOL #77015 LIGHT KIT
INSTALLATION GUIDE

Advertisement

loading
Need help?

Need help?

Do you have a question about the LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT and is the answer not in the manual?

Questions and answers

Related Manuals for LIGHT MY BRICKS LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT

Summary of Contents for LIGHT MY BRICKS LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT

  • Page 1 LEGO INDIANA JONES TEMPLE OF THE ® GOLDEN IDOL #77015 LIGHT KIT INSTALLATION GUIDE...
  • Page 2 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Light My Bricks LEGO INDIANA JONES TEMPLE OF THE ® GOLDEN IDOL 77015 INSTALLATION GUIDE Hi There! We’re here to help you get started on the LEGO ®...
  • Page 3 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® PACKAGE CONTENTS: Individual Bags Mixed Components 1 • 1x White 30cm Bit Light 2x 4-Port Micro Expansion Board 1x 2-Port Expansion Board • 5x White 30cm Micro Bit Light * 1x 6-Port Expansion Board •...

  • Page 4: Table Of Contents

    LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Contents Before You Begin Blueprint Instructions Final Product Troubleshooting Contact CONTENTS...

  • Page 5: Before You Begin

    LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Before You Begin Laying cables in between Connecting Cable and underneath bricks Connectors To Expansion Boards Cables can fit in between and underneath LEGO bricks, plates, and tiles providing ®...
  • Page 6 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Before You Begin Connecting Cable Connecting Micro Cable Connectors To Strip Lights Connectors To Micro Expansion Board Ports Take extra care when inserting connectors to ports on the Strip Lights. Connectors Take extra care when inserting the can be inserted only one way.
  • Page 7 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Before You Begin Installing Bit Lights Under Lego® Bricks And Plates When installing Bit Lights under LEGO ® pieces, ensure they are placed the correct way up (Yellow LED component exposed). You can either place them directly on top of LEGO studs or in between.
  • Page 8 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Before You Begin The Symbols Used In This Guide Connect Turn/ Flip When going through the following guide you will Used when you need to Will be found in the top left come across symbols and formats that will assist connect a LEGO piece or LMB corner when the set needs to...
  • Page 9 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Before You Begin General Note Repeat Step NOTE This is a sample note that is Repeat the previous step eg. used anywhere in this guide. It Make a spotlight, then make a Take the 5cm Connecting Cable will explain a difficult section...

  • Page 10: Blueprint

    LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® BLUEPRINT BLUEPRINT...

  • Page 11: Instructions

    LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS To ensure a smooth installation of your light kit, please read and follow each step carefully. If you run into any issues, please refer to the online troubleshooting guide.
  • Page 12 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Plate, Round 1x1 - Trans-Dark Green Plate, Round 1x1 with Open Stud Green 30cm Bit Light - Black INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 13 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Plate, Round 1x1 with Bar Handle - Black Plate, Round 1x1 with Open Stud Cool White 30cm Bit Light Arm Skeleton, Bent with Clips at - Black 90 degrees (Vertical Grip) - Black INSTRUCTIONS DISCONNECT...
  • Page 14 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Plate, Round 1x1 with Bar Handle - Black INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 15 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® NOTE Place the tower with the cables placed as shown. Connect the 1x6 LEGO Tile over the cables. Reconnect both pieces and tighten cables. INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL...
  • Page 16 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 17 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® 30cm Connecting Cable 2x Adhesive Square 6-Port Expansion Board INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 18 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Cone 1x1 Inverted with Bar - Black Plate, Round 1x1 with Open Stud - Black White 30cm Micro Bit Light Minifigure, Plume Feather Triple Compact/Flame/Water - Trans-Orange INSTRUCTIONS DISCONNECT POWER ON TEST...
  • Page 19 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® NOTE Ensure the bar is in line with the inside of the open stud as shown. INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 20 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 21 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Flicker Effects Board NOTE Connect the 5cm Connecting Cable to the “OUT” port of the Flicker Effects Board. 4-Port Micro Expansion Board 5cm Connecting Cable NOTE NOTE Take the Micro Bit Light cable Connect the 5cm Connecting...
  • Page 22 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® NOTE Take the loose 30cm Connecting Cable and connect it to the 8-Port Expansion Board. NOTE Place the components into the empty space to avoid damaging them by rotating the set over.
  • Page 23 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® NOTE Connect to a 5V USB Power Bank, 5V USB Wall Adaptor, or USB to AA Battery Pack (sold separately) If you experience any issues with the lights not working and suspect an issue with a component, please try a different port on the expansion board to verify...
  • Page 24 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® White 30cm Micro Bit Light Minifigure, Plume Feather Triple Compact/Flame/Water - Trans-Orange Cone 1x1 Inverted with Bar - Black INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID...
  • Page 25 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Brick, Round 1x1 Open Stud - Black Yellow 30cm Large Bit Light 4-Port Micro Expansion Board 15cm Connecting Cable NOTE Ensure the LED is placed halfway down the inside of the round brick.
  • Page 26 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Plate, Round 1x1 with Bar Handle - Black NOTE Ensure the spotlight is facing down in line with the golden idol. INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT...
  • Page 27 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® 15cm Connecting Cable 2-Port Expansion Board INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 28 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Minifigure, Plume Feather Triple Compact/Flame/Water - Trans-Orange Cone 1x1 Inverted with Bar - Black Plate, Modified 1x1 with Open O Clip Thick (Vertical Grip) - Light Bluish Gray White 30cm Micro Bit Light INSTRUCTIONS DISCONNECT...
  • Page 29 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® NOTE Connect the loose Micro Bit Light cable into the 4-Port Expansion Board. INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 30 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® 2x Adhesive Square INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 31 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® NOTE Connect the 15cm Connecting Cable from the 4-Port Micro Expansion Board from Step 30 into the “OUT” port of the Flicker Effects Board. NOTE Connect the other 15cm Connecting Cable into the 8-Port Expansion Board.
  • Page 32 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® If you experience any issues with the lights not working and suspect an issue with a component, please try a different port on the expansion board to verify where the fault lies (with the light or expansion board).
  • Page 33 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® White 30cm Micro Bit Light Minifigure, Plume Feather Triple Compact/Flame/Water - Trans-Orange Cone 1x1 Inverted with Bar - Black INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID...
  • Page 34 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Plate, Round 1x1 with Open Stud - Black White 30cm Bit Light Plate, Round 1x1 with Bar Handle - Black INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP...
  • Page 35 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Arm Skeleton, Bent with Clips at 90 degrees (Vertical Grip) - Black Plate, Round 1x1 with Bar Handle Plate, Round 1x1 with Open Stud - Black - Black INSTRUCTIONS DISCONNECT...
  • Page 36 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Plate, Round 1x1 with Open Stud - Black Plate, Round 1x1 with Open Stud - Black INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 37 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® NOTE Connect the loose Micro Bit Light cable into the 4-Port Micro Expansion Board. INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 38 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Plate, Round 1x1 with Open Stud White 15cm Bit Light Arm Skeleton, Bent with Clips - Black (Horizontal Grip) - Black Plate, Modified 1x2 with Bar Handle on End - Black Plate, Round 1x1 with Bar Handle - Black...
  • Page 39 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Plate 1x2 - Black Plate 2x4 - Black Plate 1x2 - Black INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 40 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 41 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® 2x Adhesive Square 2x Adhesive Square 2x Adhesive Square INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 42 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Removed Pieces NOTE You should have these parts left over that were removed from the LEGO set NOTE If you experience any issues with the lights not working and suspect an issue with a component, please try a different port on the expansion board to verify Connect to a 5V USB Power...

  • Page 43: Final Product

    LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® FINAL PRODUCT This finally completes installation of the Light My Bricks LEGO Indiana Jones Temple of the Golden Idol 77015 Light Kit. ® FINAL PRODUCT...

  • Page 44: Troubleshooting

    LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® TROUBLESHOOTING Light My Bricks lighting To prevent unnecessary If you are experiencing kits contain individual damage to components, issues with your Light components that are very...
  • Page 45 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Troubleshooting Firstly, ensure that the Check for AA batteries batteries have power using a using the AA battery pack battery charge gauge. Inside the battery pack are symbols indicating which direction the AA battery If the batteries have no power, should be inserted.
  • Page 46 INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Troubleshooting Check Your Wires In order for Light My Bricks components to fit If the wiring is detached from the LED itself, the in between and underneath LEGO bricks, the light will not operate.
  • Page 47 LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® Troubleshooting Check Your Expansion Board A short circuit can also result in overheating of the board, cable or Ports/ Strip Light Ports / batteries. If you suspect a short circuit, Effects Board Ports DISCONNECT POWER IMMEDIATELY Batteries can fail, catch fire, or even...

  • Page 48: Contact

    LEGO INDIANA JONES TEMPLE OF THE GOLDEN IDOL 77015 LIGHT KIT INSTALL GUIDE ® CONTACT US If you have an enquiry regarding the online shop, our products or a general enquiry please refer to our Frequently Asked Questions webpage here. Alternatively, you can contact our Customer Services team by visiting our online support portal here.
