Blyss NT20-12A - Ceramic Fan Heater Getting Started

Table of Contents

Contents

1 Getting started - Safety
2 In more detail - The controls
3 Connection
4 Documents / Resources
- 4.1 References
- 4.2 Download manual

Getting started - Safety

Carefully read and retain these instructions.
Before connecting the appliance, be sure that the mains voltage available matches that specified on the rating plate.
Do not use the appliance for other than its intended use. For domestic indoor use only.
Place the appliance on a flat, stable, heat-resistant surface. Operating the product in any other position could cause a hazard.
There may be trace of odour during the first few minutes of initial use. This is normal and will quickly disappear.
The heater is hot when in use. To avoid burns, do not let bare skin touch any hot surface. Use the carrying handle when moving the product.
Keep combustible material such as furniture, cushions, bedding, paper, clothes, curtains etc. at least 1m away from the heater.
Do not use the heater in areas where flammable liquids are stored or where flammable fumes may be present.
Do not cover or obstruct any of the heat outlet grilles or the air intake openings of the heater.
Do not use the heater in the rooms with explosive gas or while using inflammable solvents, varnish or glue.
Keep the heater clean. Do not allow any objects to enter any ventilation or exhaust opening as this may cause electric shock, or fire or damage to the heater.
Always unplug or disconnect the appliance from the mains power supply when not in use or when moving or cleaning it. Do not pull the cord to unplug the heater.
Do not immerse the cord, plug or any part of the appliance in water or any other liquid.
Do not attempt to repair, disassemble or modify the appliance. There are no user-serviceable parts inside.
The heater must not be located immediately below a socket-outlet.
Do not use this heater in the immediate surroundings of a bath, a shower or a swimming pool.
In order to avoid overheating, do not cover the heater.
DO NOT COVER THIS APPLIANCE WITH ITEMS SUCH AS CLOTHING, BLANKETS OR PLACE NEXT TO CURTAINS OR NET/BLINDS.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
if using an extension lead please ensure you do not exceed the maximum rated running wattage/load of the extension lead.
In order to avoid a hazard due to inadvertent resetting of the thermal cutout, this appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by the utility.

In more detail - The controls

In more detail - The controls

This appliance can be operated by the manual controls located on the top of the heater:

" 0 " — OFF position
"" — Fan only
"" — Low heating 1200W
" " — Maximum heating 2000W
" " — Adjustable thermostat

Thermostat control: Turn the thermostat switch clockwise or anti-clockwise to set the desired temperature you require. The thermostat will attempt to keep the room temperature at the desired level automatically.

Turn the thermostat clockwise to the maximum position. Once the desired room temperature is reached, turn the thermostat anti-clockwise until the heater switches off. The heater will switch on and off automatically to maintain the desired temperature.

To let the heater oscillate, turn on the oscillation button.

warning Note: Before switching off the appliance, please operate the heater for fan mode for around 20-30 seconds in order to lower the temperature of the internal part of the appliance.

Safety Control

Safety Control (Thermal Cut-Out)

This product has one non-self-resetting overheat protection devices.

In the event that the heater stops working as a result of overheating take the following immediate steps: switch the electricity off at the socket and remove the plug. Remove any objects that are covering the product. CAUTION: Do not touch the heater as it will be hot.
Set the heater switches to OFF and leave the heater to cool down fully. Once completely cool, reconnect the heater and switch it on. Do not open this product. There are no user-serviceable parts inside.

Safety Control (Tip over switch): This product is fitted with a safety tip-over switch to ensure it can only be operated in the correct upright position. If the unit is tipping over, please recover it to the upright position to operate correctly.

Storage

The product can be stored in the off-season, we recommend using the original (or appropriately sized) box. It is important to keep it in a safe, dry location.

Maintenance and cleaning

Switch off and unplug from the power supply before cleaning.
Using a soft, moist cloth, with or without a mild soap solution, carefully clean the exterior surface of the product.

Allow the product to completely cool before handling or cleaning it.
Do not allow water or other liquids to run into the interior of the product, as this could create a fire and/or electrical hazard.
We also recommend the periodic cleaning of this appliance by lightly running a vacuum cleaner nozzle over the guards to remove any dust or dirt that may have accumulated inside or on the unit.

Do not use harsh detergents, chemical cleaners or solvents as they may damage the surface finish of the plastic components.

Recycling

Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or local store for recycling advice.

Connection

This appliance is supplied with a BS1363 3 pin plug fitted with a 13 Amp fuse. Should the fuse require replacement, it must be replaced with a fuse rated at 13 Amp and approved to BS1362. In the event the mains plug has to be removed/replaced for any reason, please note:

The wires in the mains lead are coloured in accordance with the following code:
Blue – Neutral
Brown – Live

As the colours of the wires in the mains leadof this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows. The blue wire must be connected to the terminal marked with an N or coloured black. The brown wire must be connected to the terminal marked with an L or coloured red.
