INSTALLATION AND OPERATING
INSTRUCTIONS
4-20mA EMS
Interface
Adds 4-20mA Setpoint
capability to
TempTracker Mod+
Control System
IMPORTANT SAFETY INSTRUCTIONS. READ AND FOLLOW ALL
INSTRUCTION. SAVE THESE INSTRUCTIONS.
NOTE: These instruction are for the use of qualified individuals specially trained and experienced in the
installation and maintenance of this type of equipment and related system components. Installation and service
personnel are required by some states to be licensed. Persons not qualified shall not attempt to install, service,
or maintain this equipment.
These instructions should be maintained in legible condition and kept adjacent to the vunit or in a safe place for
future use.
APPROVED
UNCONTROLLED DOCUMENT IF PRINTED
4-20 mA EMS
4-20mA INPUT
+
Signal GND
2
1
3
Effective: 07-30-21
Replaces: 11-20-07
P/N 241323 Rev. 3
RS485
EXTENSION
CONNECTORS
