Skil-Care 909510 Instruction Manual

Model# 909510
Re-Order #
909376
909377
909397
909367
909510
909378
909398
*One Year Guarantee
The Gel-Foam Toilet Seat Cushion Alarm System incorporates a top layer of gel and a bottom
layer of foam to provide comfort and maximum pressure relief. The baffled gel pack design stabilizes
the gel to insure that the gel doesn't migrate away from the high pressure areas. The heat-sealed vinyl
casing is water proof and cleans easily with disinfectants and is soft and gentle to the skin.

Installation of Toilet Seat Sensor:

Make sure that the cable is facing the back, away from the split. The toilet seat cushion should be
placed over the toilet seat with the gel surface facing up. The toilet seat cushion is designed to be
placed on most toilet seats and is held in place by four removable straps as shown in (Fig. 1).
Each strap is to be threaded through both rectangular rings (Fig. 2) and are closed by placing the end
of the strap on top of the opposing side. The strap should be pulled snug but not too tight. All toilet
seat cushion alarms have a sensor imbedded in the cushion and are guaranteed for one year.
Model 909376 includes the ChairPro electronic unit in addition to the cushion and imbedded sensor.
Model 909377 substitutes the ChairPro alarm with the MultiPro alarm. The MultiPro alarm system
should be used when in addition to an audible alarm, the caregiver is interested in a nurses call
interface. Please refer to the Skil-Care catalog or website www.skil-care.com for specifics on the
ChairPro and MultiPro electronic units.
Fig. 1
Model# 909367
Description
Gel-Foam Toilet Seat Cushion Alarm System* (ChairPro Unit)
Gel-Foam Toilet Seat Cushion Alarm System*(MultiPro Unit)
Replacement Straps
ChairPro Alarm Unit Only
MultiPro Alarm Unit Only
Gel-Foam Toilet Seat Replacement Cushin w/Sensor
Universal Wall Bracket
See reverse side for Easy Care Instructions
Gel-Foam Toilet Seat Cushion Alarm System

Purpose

Easy to Use

Rectangular Rings
Units
Set
Set
6/pk of 4
Ea.
Ea.
Set
Ea.
Fig. 2
