- Page 1 314000 314000 PX 200 DECKENRING PX 200 CEILING RING Aufbauanleitung User manual www.pixlip.com...
-
Page 2: Table Of Contents
INSTALLATION STRUTS PLANUNG LED VERTEILUNG PLANING LED DISTRIBUTION EINBAU PX LED MODULE INSTALLATION PX LED MODULES EINBAU PX KABEL INSTALLATION PX CABLE ANBRINGUNG Y-KABEL CONNECTING Y-CABLE MONTAGE REUTLINGER AUFHÄNGUNG MOUNTING REUTLINGER SUSPENSION EINSPANNUNG TEXTIL TEXTILE TENSIONING INHALT | CONTENT www.pixlip.com... -
Page 3: Komponenten Components
KOMPONENTEN COMPONENTS 45 Grad Winkel PX 200 Profile Rahmenlängsverbindungen PX 200 45 Grad Profile 45 Degrees angles PX 200 Profiles Frame straight conncections PX 200 45 Grad Profiles Strebenhalter Streben PX LED Module PX Kabel Strut holders Struts PX LED modules... -
Page 4: Aufbau Construction
Schieben Sie die 45 Grad Winkel in die Enden der Längsprofile. | Insert the 45 degrees an- gles into the endings of the PX 200 profiles. 45 Grad Winkel | 45 Degrees angle PX 200 Profil | PX 200 profile RAHMENLÄNGSVERBINDUNG... -
Page 5: Montage 45 Grad Profile Mounting 45 Degrees Profiles
45 degrees profile lies in the strut bracket. Repeat these steps also for MOUNTING TOP PROFILE the milled recess of the PX 200 profile. Fix the the upper part of the strut. Place the mounted bolts by tighten them with a socket screw key. -
Page 6: Planung Led Verteilung
PX LED Module und Y-Kabel montiert werden können. |The upper illus- trations show possibilities to mount the PX LED modules and Y-cables. PX LED Modul | PX LED module PX Kabel | PX cable AUFBAU | CONSTRUCTION www.pixlip.com... -
Page 7: Einbau Px Kabel
Verkabelung von Fachpersonal oder einem Messebauer ausführen bzw. kontrollieren! | To guarantee a correct construction of the PX LED modules including the power supply execute the planning and wiring by qualified personnel or a stand builder. AUFBAU | CONSTRUCTION www.pixlip.com... -
Page 8: Montage Reutlinger Aufhängung Mounting Reutlinger Suspension
Reutlinger Sets | Reutlinger sets Abhängebolzen | Hanging bolts AUFBAU | CONSTRUCTION www.pixlip.com... -
Page 9: Einspannung Textil Textile Tensioning
PX frame segment. Repeat the process also for the textiles at the outside and inside. Textil | Textile AUFBAU | CONSTRUCTION www.pixlip.com... - Page 10 PX 200 DECKENRING | PX 200 CEILING RING AUFBAUANLEITUNG | USER MANUAL © 2019 PIXLIP GmbH Raiffeisenstraße 17 40764 Langenfeld Germany info@pixlip.com www.pixlip.com...
