Sunset Furniture Sunset Trading DLU-TPD-4242-B Assembly Instructions

701 E Industrial Pk Dr
Manchester, NH 03109
sunsettrading.com
1 Turn the under side of the Table Top over
and place it on a clean and smooth surface
such as rug or carpet to avoid the Table Top from
being scratched .
01
4 Fix the Pedestal with Flat Washer,Spring Washer & Hex Nut
using the Spanner to tighten it.
d
c
b
a
03
Thank you for purchasing this quality
product! It has been engineered for easy
assembly yet constructed for durability.
Please take the time to read and follow
the instructions while assembling.
Fix the Footing to the Pedestal with
2
the Flat Washer,Spring Washer And Hex Nut
using the Spanner to tighten it.
Remove the plastic
cover from the
Pedestal and Footings.
03
Remove the strip before start Assembly .
Mouting Plate
01
Please Contact us if you are
Missing Parts or have any Questions
info@sunsettrading.com
Repeat the same step for the other three Footing .
3
03
03
b
c
02
d
03
02
01
ASSEMBLY INSTRUCTIONS
877-364-8464
a
03
02
SKU: DLU-TPD-4242-B
SKU: DLU-TPD-4242-CB

List of Parts For 1 Set

Table Top
1
01
01
Pedestal
02 1
Table Leg
03 4
With Leveler

List of Hardware For 1 Set

Flat Washer
a
12
5
" x 22mm
16
Spring Washer
b
12
5
"
16
Hexagon Nut
c 12
5
" x 7mm
16
Spanner
d
1
12.8mm

IMPORTANT NOTES:

• Keep all hardware and small parts
out of reach of children.
• Remove all staples and packing
straps before you start to assemble.
• Do not discard main cartons and
wrapping material until assembly is
complete.
• Check to be sure you have all parts
and hardware.
• Place all wooden parts on a clean
soft surface to avoid parts from
being scratched.
• Do not tighten all screws / bolts until
completely assembled.
• Check tightness 3x's/year, with use
screws can become loose.
• Do not attempt to repair or modify
parts that are broken or defective.
Please contact us immediately.
• Enjoy your new furniture!
MADE IN MALAYSIA
