  • Page 1 M U R P H Y B E D 20 2 3 M A N UA L...

  • Page 3: Table Of Contents

    Options and Equipment Service Assistance Reporting Safety Defects 2. GENERAL INFORMATION Floor Plan Exterior Equipment Location Beds and Seating Leisure Lounge Plus System (optional) Leisure Lounge Plus Seating Leisure Lounge Seating TV Location 3. SCHEMATICS Electrical 12 volt Electrical Reference...

  • Page 5: Introduction

    Your Leisure Travel Vans Dealer or Triple E RV Customer operation. Service at: Before your first drive, become familiar with the Email: info@tripleerv.com...

  • Page 6: Motorhome Information Kit

    • Awning after purchase. OPTIONS AND EQUIPMENT Leisure Travel Vans are available in various sizes and floor plan configurations and with differing optional equipment. The equipment, accessories and components described in this manual may not apply in all respects to your motorhome.

  • Page 7: Reporting Safety Defects

    MODEL SPECIFIC MANUAL 1. INTRODUCTION REPORTING SAFETY DEFECTS If you suspect your motorhome has a safety defect that could cause injury or death, immediately contact Triple E RV. Also, contact the National Highway Traffic Safety Administration (NHTSA) in the US or Transport Canada to report your concern.

  • Page 9: General Information

    MODEL SPECIFIC MANUAL 2. GENERAL INFORMATION 2. GENERAL INFORMATION FLOOR PLAN LEISURE LOUNGE 32 31 Macerator Option Under Floor Fire Extinguisher Shower Utility Center Under Floor Solar Controller, Inverter Remote, Fridge (2A fuse behind Exterior Water Tank/Drain Under Floor and Water Heater Dial above...
  • Page 10 2. GENERAL INFORMATION MODEL SPECIFIC MANUAL LEISURE LOUNGE PLUS 32 31 Macerator Option Under Floor Fire Extinguisher Fridge (2A fuse behind Exterior Utility Center Under Floor Solar Controller, Inverter Remote, vent) Microwave Above Water Tank/Drain Under Floor and Water Heater Dial above...

  • Page 11: Exterior Equipment Location

    MODEL SPECIFIC MANUAL 2. GENERAL INFORMATION EXTERIOR EQUIPMENT LOCATION PASSENGER SIDE VIEW Light Entrance Step Compartment Refrigerator Vents BBQ Hook-Up Furnace Exhaust External Receptacle Storage Compartment Generator Compartment Awning I n v e r t e r a n d S t o r a g e Ladder DRIVER SIDE VIEW Awning...
  • Page 12 2. GENERAL INFORMATION MODEL SPECIFIC MANUAL TOP VIEW Solar Panel (Optional) Air Conditioner Stack Vent Roof Vent WiFi/TV Antenna Sky Light Satellite (Optional) 1 1 1 REV September 22, 2022...

  • Page 13: Beds And Seating

    BEDS AND SEATING while you swivel the seat. Release the lock button when the chair is slightly rotated to ensure the seat LEISURE LOUNGE PLUS SYSTEM locks into the next position. (OPTIONAL) 5. Remove the lounge chair seat back cushions and...
  • Page 14 2. GENERAL INFORMATION MODEL SPECIFIC MANUAL   ᘐ CAUTION RAISING THE MURPHY BED Failure to pull the release strap will cause damage to the Murphy Bed 1. Pull the adjustable headboard/backrest toward you for desired comfort. To collapse headboard/ backrest, pull it out all the way and it will release. Push it back toward the wall.

  • Page 15: Leisure Lounge Plus Seating

    : You can rotate the chairs by LEISURE LOUNGE PLUS SEATING lifting and holding the lock button on the side Leisure lounge recliners can be configured as follows: of the chair and releasing the lock when the chair is at the desired angle. • Coffee Table : Use the small flip-up coffee table/ support for a dinette table or to support large table.

  • Page 16: Leisure Lounge Seating

    2. GENERAL INFORMATION MODEL SPECIFIC MANUAL 4. Bed down with the headboard tilted out as LEISURE LOUNGE SEATING backrest 1. Bench configuration 2. Seats with table configuration 3. Seats pulled out (Pull out seats before lowering Murphy bed) REV September 22, 2022...

  • Page 17: Tv Location

    MODEL SPECIFIC MANUAL 2. GENERAL INFORMATION TV LOCATION The TV is stowed in the coach passenger side countertop and is accessed by pulling the release lever located at the coach entrance. NOTE: The TV will rise from the cabinet under spring tension.

  • Page 19: Schematics

    MODEL SPECIFIC MANUAL 3. SCHEMATICS 3. SCHEMATICS ELECTRICAL 12 VOLT ELECTRICAL REFERENCE REV September 22, 2022...

  • Page 20: 120 Volt Electrical Reference

    3. SCHEMATICS MODEL SPECIFIC MANUAL 120 VOLT ELECTRICAL REFERENCE REV September 22, 2022...

  • Page 21: Electrical Schematic

    MODEL SPECIFIC MANUAL 3. SCHEMATICS ELECTRICAL SCHEMATIC BBGC2H BBGC2H LITHIUM LITHIUM VOLT VOLT BATTERRY BATTERRY REV September 22, 2022...
  • Page 22 3. SCHEMATICS MODEL SPECIFIC MANUAL REV September 22, 2022...
  • Page 23 MODEL SPECIFIC MANUAL 3. SCHEMATICS 40A AUTO RESET TYPE I REV September 22, 2022...
  • Page 24 3. SCHEMATICS MODEL SPECIFIC MANUAL BROWN (GROUND) DARK GREEN (LICENSE) WHT/DK BLUE (REVERSE) BLACK (RIGHT SIGNAL) RED (BRAKE LIGHT) GY/BR (FOG LT) GRAY (CLEARANCE LIGHTS) GRAY (CLEARANCE LIGHTS) GY/BR (FOG LT) RED (BRAKE LIGHT) BLACK (LEFT SIGNAL) WHT/DK BLUE (REVERSE) GY/DG (LICENSE LT) BROWN (GROUND) REV September 22, 2022...
  • Page 25 MODEL SPECIFIC MANUAL 3. SCHEMATICS REV September 22, 2022...
  • Page 26 3. SCHEMATICS MODEL SPECIFIC MANUAL REV September 22, 2022...

  • Page 27: Plumbing

    MODEL SPECIFIC MANUAL 3. SCHEMATICS PLUMBING WATER LINES SCHEMATIC REV September 22, 2022...

  • Page 28: Drain Line Schematic

    3. SCHEMATICS MODEL SPECIFIC MANUAL DRAIN LINE SCHEMATIC 3-10 REV September 22, 2022...

  • Page 29: Entertainment

    MODEL SPECIFIC MANUAL 3. SCHEMATICS ENTERTAINMENT REV September 22, 2022 3-11...

  • Page 30: Satellite Pre-Wire

    3. SCHEMATICS MODEL SPECIFIC MANUAL SATELLITE PRE-WIRE If your coach did not come with the optional satellite dish, it will be pre-wired for installation at a later date if you so choose. Location of the prewire will vary by floorplan. 3-12 REV September 22, 2022...
  • Page 31 MODEL SPECIFIC MANUAL NOTES NOTES REV September 22, 2022 Notes-i...
  • Page 32 NOTES MODEL SPECIFIC MANUAL NOTES Notes-ii REV September 22, 2022...
  • Page 33 LTV Roadside Assistance 4287 Beltline Road, Box #198 Addison, TX 75001 for EMERGENCY ROADSIDE CALL 1•877•219•3831...
  • Page 34 Triple E Recreational Vehicles and Leisure Travel Vans are brands and trademarks of Triple E Canada Ltd. 301 Roblin Blvd., Box 1230 Winkler, MB Canada R6W 4C4 Telephone: 204-325-4361 Fax: 204-325-5241 US Address: P.O. Box 68 Walhalla, ND 58282 www.tripleerv.com • info@tripleerv.com • www.leisurevans.com • general@leisurevans.com Product improvement is a continuing process at Triple E Recreational Vehicles.
