Leisure WONDER 2022 Manual

Rear twin bed
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
R E A R T W I N B E D
20 2 2 M A N UA L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WONDER 2022 and is the answer not in the manual?

Questions and answers

Gordon & Karen Brown
June 14, 2025

all electrical is not working to van (lights,water pump ect) Have it plugged in and fridge and tv are qorking

0

Subscribe to Our Youtube Channel

Related Manuals for Leisure WONDER 2022

Summary of Contents for Leisure WONDER 2022

  • Page 1 R E A R T W I N B E D 20 2 2 M A N UA L...

  • Page 3: Table Of Contents

    MODEL SPECIFIC MANUAL TABLE OF CONTENTS TABLE OF CONTENTS 120 Volt Electrical Reference Electrical Schematic 1. INTRODUCTION Plumbing Supplemental Manual Water lines schematic Motorhome Information Kit Drain line schematic Options and Equipment Entertainment 4-10 Service Assistance Satellite Pre-wire 4-11 Reporting Safety Defects 2.
  • Page 5 Your Leisure Travel Vans Dealer or Triple E RV Customer operation. Service at: Before your first drive, become familiar with the Email: info@tripleerv.com...

  • Page 6: Entertainment

    • Awning after purchase. OPTIONS AND EQUIPMENT Leisure Travel Vans are available in various sizes and floor plan configurations and with differing optional equipment. The equipment, accessories and components described in this manual may not apply in all respects to your motorhome.

  • Page 7: Reporting Safety Defects

    MODEL SPECIFIC MANUAL 1. INTRODUCTION REPORTING SAFETY DEFECTS If you suspect your motorhome has a safety defect that could cause injury or death, immediately contact Triple E RV. Also, contact the National Highway Traffic Safety Administration (NHTSA) in the US or Transport Canada to report your concern.

  • Page 9: General Information

    MODEL SPECIFIC MANUAL 2. GENERAL INFORMATION 2. GENERAL INFORMATION FLOOR PLAN REV December 02, 2021...

  • Page 10: Exterior Equipment Location

    2. GENERAL INFORMATION MODEL SPECIFIC MANUAL EXTERIOR EQUIPMENT LOCATION PASSENGER SIDE VIEW Light BBQ Hook-Up Awning External Receptacle Storage Compartment Ladder (Optional) Generator Compartment Electrical Step Fridge Vents DRIVER SIDE VIEW Sewer Termination Utility Center Furnace Vent Fuel Fill Storage Compartment Battery Compartment Sewer Hose (Behind Doors) Propane Shut-Off...
  • Page 11 MODEL SPECIFIC MANUAL 2. GENERAL INFORMATION TOP VIEW Skylight Solar Panels (Optional) Awning Stack Vent Roof Vent Radio Antenna Satellite (Optional) TV/WiFi Antenna REV December 02, 2021...

  • Page 12: Beds And Seating

    2. GENERAL INFORMATION MODEL SPECIFIC MANUAL which you can mount your removable table: BEDS AND SEATING • Attached to the front Driver Side Dinette COMBINING THE TWIN BEDS • Attached between the rear twin beds 1. Flip out the bed extension located between the beds.
  • Page 13 MODEL SPECIFIC MANUAL 2. GENERAL INFORMATION 5. Adjust the position and rotation of the table to your liking, and tighten handles secure in place. REMOVING THE TABLE Follow steps 1 through 5 above in reverse order to remove and store the table. REV December 02, 2021...

  • Page 15: Firefly Multiplex System

    MODEL SPECIFIC MANUAL 3. FIREFLY MULTIPLEX SYSTEM 3. FIREFLY MULTIPLEX CLIMATE CONTROL The Home screen also gives you basic information SYSTEM and control of the climate control. It will display the current climate control mode, the current temperature, and allow you to adjust the internal temperature by touching the up and down arrows.

  • Page 16: Lights Screen

    3. FIREFLY MULTIPLEX SYSTEM MODEL SPECIFIC MANUAL To enable AGS, tap on the Enable/Disable toggle LIGHTS SCREEN button . You will have to confirm you want the AGS This screen will control the lighting for the entire turned on by following the screen prompts. coach, including the exterior, as well as adjust the  ...

  • Page 17: Climate Screen

    MODEL SPECIFIC MANUAL 3. FIREFLY MULTIPLEX SYSTEM Heat Pump will run until the current temp reaches SETTINGS your desired temp and then shut off. • Quiet Time Start/Stop : Between these hours, : Tap to operate the Furnace. The • Furnace the AGS will not attempt to automatically start the Furnace will run until the current temp reaches generator.

  • Page 18: Settings Screen

    3. FIREFLY MULTIPLEX SYSTEM MODEL SPECIFIC MANUAL SETTINGS SCREEN The Settings screen contains the general settings for the multiplex system. To activate the Settings screen, tap on the Settings icon in the left navigation. CHANGING TEMPERATURE UNITS To change between Fahrenheit and Celsius for the climate control, tap on either C or F to set the preferred units.

  • Page 19: Troubleshooting

    MODEL SPECIFIC MANUAL 3. FIREFLY MULTIPLEX SYSTEM TROUBLESHOOTING If you press a switch panel button and the operational LED does not illuminate, you’ll need to change the battery. Simply use your fingers to pry the switch panel away from the wall-mounted backplate to access the battery compartment on the back of the switch.

  • Page 21: Schematics

    MODEL SPECIFIC MANUAL 4. SCHEMATICS 4. SCHEMATICS ELECTRICAL 12 VOLT ELECTRICAL REFERENCE REV December 02, 2021...
  • Page 22 4. SCHEMATICS MODEL SPECIFIC MANUAL 120 VOLT ELECTRICAL REFERENCE REV December 02, 2021...
  • Page 23 MODEL SPECIFIC MANUAL 4. SCHEMATICS ELECTRICAL SCHEMATIC REV December 02, 2021...
  • Page 24 4. SCHEMATICS MODEL SPECIFIC MANUAL REV December 02, 2021...
  • Page 25 MODEL SPECIFIC MANUAL 4. SCHEMATICS REV December 02, 2021...
  • Page 26 4. SCHEMATICS MODEL SPECIFIC MANUAL REV December 02, 2021...
  • Page 27 MODEL SPECIFIC MANUAL 4. SCHEMATICS REV December 02, 2021...
  • Page 28 4. SCHEMATICS MODEL SPECIFIC MANUAL PLUMBING WATER LINES SCHEMATIC REV December 02, 2021...
  • Page 29 MODEL SPECIFIC MANUAL 4. SCHEMATICS DRAIN LINE SCHEMATIC REV December 02, 2021...
  • Page 30 4. SCHEMATICS MODEL SPECIFIC MANUAL ENTERTAINMENT 4-10 REV December 02, 2021...
  • Page 31 MODEL SPECIFIC MANUAL 4. SCHEMATICS SATELLITE PRE-WIRE If your coach did not come with the optional satellite dish, it will be pre-wired for installation at a later date if you so choose. Location of the prewire will vary by floorplan. REV December 02, 2021 4-11...
  • Page 33 MODEL SPECIFIC MANUAL NOTES NOTES REV December 02, 2021 Notes-i...
  • Page 34 NOTES MODEL SPECIFIC MANUAL NOTES Notes-ii REV December 02, 2021...
  • Page 35 LTV Roadside Assistance 4287 Beltline Road, Box #198 Addison, TX 75001 for EMERGENCY ROADSIDE CALL 1•877•219•3831...
  • Page 36 Triple E Recreational Vehicles and Leisure Travel Vans are brands and trademarks of Triple E Canada Ltd. 301 Roblin Blvd., Box 1230 Winkler, MB Canada R6W 4C4 Telephone: 204-325-4361 Fax: 204-325-5241 US Address: P.O. Box 68 Walhalla, ND 58282 www.tripleerv.com • info@tripleerv.com • www.leisurevans.com • general@leisurevans.com Product improvement is a continuing process at Triple E Recreational Vehicles.
