  • Page 1 Version A - 01/19 Service Manual CPi2000 Cinema Processor...
  • Page 2 CPi2000 Service Manual Version A - 01/19 Table of Contents Safety and Compliance Introduction Datasheets and Specifications Board Layouts Main (PCB) Schematics Main Bill of Materials...

  • Page 3: Safety Instructions

    CPi2000 Service Manual Version A - 01/19 SAFETY INSTRUCTIONS For your own safety and to avoid invalidation of the warranty please read this section carefully. IMPORTANT SYMBOLS Caution Alerts the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
  • Page 4 CPi2000 Service Manual Version A - 01/19 damaged in any way such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

  • Page 5: Gui Software

    CPi2000 Service Manual Version A - 01/19 CPi2000 CINEMA PROCESSOR HIGHTLIGHTS Built-in Crossover Converts up to 7.1 channel audio to passive, bi- amp or tri-amp Supports TMS Communication Convenient for remote control and saves system operation cost JBL Cinema Speaker Presets Reduces tuning time Specifically-designed GUI Software Makes operation intuitive and simple...

  • Page 6: Front Panel Controls

    CPi2000 Service Manual Version A - 01/19 CPi2000 CINEMA PROCESSOR FRONT PANEL CONTROLS • • LCD Display: The display is 320x160 pixels. When the Digital Input Button: Press the button to choose signal unit is powered on, the home screen shows the hall from the Digital Input Connector.

  • Page 7: Application Example

    CPi2000 Service Manual Version A - 01/19 CPi2000 CINEMA PROCESSOR APPLICATION EXAMPLE RTA Microphone Cinema Server Control PC 100-240V 50/60Hz CD/DVD Player CROWN CROWN CROWN CROWN CROWN XLC2500 XLC2500 XLC2500 XLC2800 XLC2500 FAULT FAULT FAULT FAULT FAULT CLIP CLIP CLIP CLIP CLIP SIGNAL...

  • Page 8: Specifications

    Webchat Website © 2017 HARMAN International Industries, Incorporated. All rights reserved. JBL is a trademark of HARMAN International harmanpro, registered in the United States and / or other countries. Features, specifications and appearance are subject to change without notice. www.jblpro.com...

  • Page 9: Board Layouts

    CPi2000 Service Manual Version A - 01/19 Board Layouts Table of Contents...
  • Page 10 " ■ CPi2000 Service Manual Version A - 01/19 • • •• ;:::::: •••••s CPi2000 Moinboard 5069499_F i�i r,1 ... -..: ....-.:·1 • • • • .,,;, � � 0 O Cl • ft= � == �C} 5069499_F ---------------- 100-�l't'NY ·:::::::::::.��...
  • Page 11 ASY/SCH PART NO. DATE RoHS COMPLIANCE WITH THE FIRST ARTICLE. 5069500 PCB,RAW,CPi2000,BDB ENGINEER Log Li 20DEC2017 PROPRIETARY AND CONFIDENTIAL PROPERTY OF HARMAN. DO NOT DISCLOSE, REPRODUCE, OR SCALE SCH DOC NO. PCB PART NO. SHEET PUBLISH WITHOUT APPROVAL. NONE 1000237999 5069499...
  • Page 12 CPi2000 Service Manual Version A - 01/19 L-_IN L-_IN L101 2.5K L103 2.5K L-_RELAY_IN C-_IN L301 2.5K L303 2.5K C-_RELAY_IN L+_IN L-_IN L-_RELAY_IN C-_IN C-_RELAY_IN 2.5K 2.5K 2.5K 2.5K L+_IN L102 L104 L+_RELAY_IN C+_IN L302 L304 C+_RELAY_IN BLS-_IN L+_IN L+_RELAY_IN C+_IN C+_RELAY_IN BLS+_IN...
  • Page 13 CPi2000 Service Manual Version A - 01/19 C107 120pF C507 120pF R105 R106 R505 R506 C455 120pF C105 C505 47uF 4.02K 2.21K 47uF 4.02K 2.21K R1177 R699 R103 R1159 24.9K 24.9K C930 L+_S LS-_S 47uF L+_S LS-_S 4.02K 2.21K R598 C_L_IN_S LS_IN_S C_L_IN_S...
  • Page 14 CPi2000 Service Manual Version A - 01/19 +12V_PSU_S L-_OUT2 L-_OUT1 L-_OUT2 L-_RELAY_IN L+_OUT1 L+_OUT2 L-_S C_L_IN_S L_IN_S 2-1462037-3 C_L_IN_S I/O_0 L_IN_S 2-1462037-3 SG77 SPARK GAP SG65 SPARK GAP NONSYNC_L_IN_S L-_OUT1 NONSYNC_L_IN_S I/O_1 L-_OUT1 MIC_IN_S SG76 SPARK GAP SG64 SPARK GAP L+_OUT1 MIC_IN_S I/0_2...
  • Page 15 CPi2000 Service Manual Version A - 01/19 R111 +5.0VA +5.0VA +12V_2 +12V_2 C110 120pF R112 R117 R217 C190 C192 R_LF+ L_AD_IN+ C109 AINL+ AOUTA1+ R_LF+ 2.67K 2.67K 0.1uF 0.1uF VQ11 VQ12 L_IN_M R_LF- L_IN_M AOUTA1- R_LF- R115 C112 NJM4580CG 47uF 0.0027uF L_LF+ AOUTB1+...
  • Page 16 CPi2000 Service Manual Version A - 01/19 R311 +5.0VA +5.0VA +12V_2 +12V_2 C310 120pF R312 R317 R417 C218 C236 R_MF+ C_AD_IN+ C309 AINL+ AOUTA1+ R_MF+ VQ21 2.67K VQ22 2.67K C_IN_M 0.1uF 0.1uF R_MF- C_IN_M AOUTA1- R_MF- R315 C312 NJM4580CG 47uF 0.0027uF C_LF+ AOUTB1+...
  • Page 17 CPi2000 Service Manual Version A - 01/19 R511 +5.0VA +5.0VA +12V_2 +12V_2 C510 120pF R1195 R517 R1192 C317 C319 BLS+ LS_AD_IN+ C509 AINL+ AOUTA1+ BLS+ 2.67K 2.67K 0.1uF 0.1uF VQ31 VQ32 LS_IN_M BLS- LS_IN_M AOUTA1- BLS- R515 C512 NJM4580CG 47uF 0.0027uF AOUTB1+ R510...
  • Page 18 CPi2000 Service Manual Version A - 01/19 R711 +5.0VA +5.0VA +12V_2 +12V_2 C710 120pF R712 R717 R817 C345 C348 BLS_AD_IN+ C709 AINL+ AOUTA1+ 2.67K 2.67K 0.1uF 0.1uF VQ41 VQ42 BLS_IN_M BLS_IN_M AOUTA1- R715 C712 NJM4580CG 47uF 0.0027uF BRS+ AOUTB1+ BRS+ R709 R710 C711...
  • Page 19 CPi2000 Service Manual Version A - 01/19 OUTPUT_MUTE OUTPUT_MUTE R144 R146 475K 475K R134 C126 22pF R130 C128 2.5K 2.5K L_MF-_OUT_M L_MF- R120 R122 5.49K R126 R129 R138 15.4 R140 15.4 L105 L107 L_MF- L_MF-_OUT_M 220uF C123 120pF C121 Q101 Q103 NJM4580CG 0.0027uF...
  • Page 20 CPi2000 Service Manual Version A - 01/19 OUTPUT_MUTE OUTPUT_MUTE R1212 R1023 475K 475K R786 C787 22pF NJM4580CG R1147 C771 2.5K 2.5K L_LF- R887 R987 5.49K R971 R999 R905 15.4 R906 15.4 L_LF-_OUT L_LF- L_LF-_OUT 220uF C899 120pF C865 0.0027uF R930 MMBF170 R931 SG14...
  • Page 21 CPi2000 Service Manual Version A - 01/19 OUTPUT_MUTE OUTPUT_MUTE R244 R246 475K 475K R234 C226 22pF NJM4580CG R1148 C228 2.5K 2.5K C_MF-_OUT_M C_MF- R220 R222 5.49K R226 R229 R238 15.4 R240 15.4 L205 L207 C_MF- C_MF-_OUT_M 220uF C223 120pF C221 Q201 Q203 0.0027uF...
  • Page 22 CPi2000 Service Manual Version A - 01/19 OUTPUT_MUTE OUTPUT_MUTE R1030 R1031 475K 475K R852 C793 22pF NJM4580CG R799 C775 2.5K 2.5K C_LF- R891 R991 5.49K R975 R1003 R913 15.4 R914 15.4 C_LF-_OUT C_LF- C_LF-_OUT 220uF C869 C678 120pF 0.0027uF R938 MMBF170 R939 SG48...
  • Page 23 CPi2000 Service Manual Version A - 01/19 OUTPUT_MUTE OUTPUT_MUTE R1034 R1035 R860 475K 475K C794 22pF R855 C777 R_MF- R893 R993 5.49K R977 R1005 R917 15.4 R918 15.4 2.5K 2.5K R_MF-_OUT R_MF- R_MF-_OUT 220uF C913 C871 120pF NJM4580CG 0.0027uF R942 MMBF170 R943 SG50...
  • Page 24 CPi2000 Service Manual Version A - 01/19 OUTPUT_MUTE OUTPUT_MUTE R374 R376 R364 475K 475K C356 22pF NJM4580CG R360 C358 R350 R352 5.49K R356 R359 R368 15.4 R370 15.4 L309 2.5K L311 2.5K LS-_OUT_M LS-_OUT_M 220uF C353 C351 120pF Q305 Q307 0.0027uF R372 MMBF170...
  • Page 25 CPi2000 Service Manual Version A - 01/19 +3.3V LEFT1_CH1_AMP_STA CENTER1_CH1_AMP_STA RIGHT1_CH2_AMP_STA LEFT1_CH1_AMP_STA CENTER1_CH1_AMP_STA RIGHT1_CH2_AMP_STA LEFT1_CH1_LOAD_STA CENTER1_CH1_LOAD_STA RIGHT1_CH2_LOAD_STA LEFT1_CH1_LOAD_STA CENTER1_CH1_LOAD_STA RIGHT1_CH2_LOAD_STA LEFT1_CH2_AMP_STA CENTER1_CH2_AMP_STA LS_RS1_CH1_AMP_STA C189 U74HC165-S LEFT1_CH2_AMP_STA CENTER1_CH2_AMP_STA LS_RS1_CH1_AMP_STA 0.1uF LEFT1_CH2_LOAD_STA CENTER1_CH2_LOAD_STA LS_RS1_CH1_LOAD_STA LEFT1_CH2_LOAD_STA CENTER1_CH2_LOAD_STA LS_RS1_CH1_LOAD_STA LEFT2_CH1_AMP_STA CENTER2_CH1_AMP_STA LS_RS1_CH2_AMP_STA LEFT2_CH1_AMP_STA CENTER2_CH1_AMP_STA LS_RS1_CH2_AMP_STA LEFT2_CH1_LOAD_STA CENTER2_CH1_LOAD_STA...
  • Page 26 CPi2000 Service Manual Version A - 01/19 OUTPUT_MUTE OUTPUT_MUTE R744 R746 R734 475K 475K C726 22pF NJM4580CG C931 BLS- R1143 R722 5.49K R726 R526 R738 15.4 R740 15.4 L705 2.5K L707 2.5K BLS-_OUT_M BLS- BLS-_OUT_M 220uF C723 C932 120pF Q701 Q703 0.0027uF R742...
  • Page 27 CPi2000 Service Manual Version A - 01/19 OUTPUT_MUTE OUTPUT_MUTE R444 R446 475K 475K R434 C426 22pF R430 C428 2.5K 2.5K R420 R422 5.49K R426 R429 R438 15.4 R440 15.4 L405 L407 SW-_OUT_M SW-_OUT_M 220uF C421 C423 120pF Q401 Q403 NJM4580CG 0.0027uF R442 MMBF170...
  • Page 28 CPi2000 Service Manual Version A - 01/19 +3.3V +3.3V LCD_+3.3V +3.3V BACKLIGHT_+3.3V +3.3V FDN308P CLOSE TO SOCKET > 3MM I=3mA I=1mA SPI1_MOSI_M R523 SPI1_MOSI_M VBAT I=80mA SPI1_MISO_M R525 L136 C446 0.1uF SPI1_MISO_M VCCIF SPI1_SPCK_M R524 SPI1_SPCK_M SCLK VCC1 RTC_CE_M I=0.5uA C944 C943 C945...
  • Page 29 CPi2000 Service Manual Version A - 01/19 +5.0VD R1238 +12V_PSU +12V +12V_PSU R531 C939 R399 C147 +5.0VA 10uH 0.1uF 10uF I=100mA SS14_NL 100K R1189 R1187 EN/SYNC R419 4.99 4.99 10uH I=400mA C143 C566 + C597 C595 0.1uF 10uF 100uF 100uF R1229 100K 39.2K...
  • Page 30 SUPPLIER SHALL PROVIDE A CERTIFICATE OF SIZE ASY/SCH PART NO. DATE RoHS COMPLIANCE WITH THE FIRST ARTICLE. Engineer 5079216 20DEC2017 PROPRIETARY AND CONFIDENTIAL PROPERTY OF HARMAN. DO NOT DISCLOSE, REPRODUCE, OR SCALE SCH DOC NO. PCB PART NO. SHEET PUBLISH WITHOUT APPROVAL. NONE 1000290874 5079218...

  • Page 31: Ethernet Phy

    CPi2000 Service Manual Version A - 01/19 ETHERNET PHY NOTE: PHY strapped for 100Mb, Full Duplex, AutoNeg Off. uC MAC unable to sense 10Mb operation on RMII. KSZ8081 R223 REF_CLK/B-CAST_OFF pin28=PU) PHY_REFCLK C171 CONFIG = RMII (Config2,1 = Int. PD, PHY_TXD1 Speed= 100Mb (pin 31 = Interal PU) TXD1...
  • Page 32 CPi2000 Service Manual Version A - 01/19 DA700204 0.1uF C112 2.5K R248 AES_CH1-2+_IN R162 2.5K TG01-1006N2 R251 AES_CH1-2-_IN IND LG01-0346N2 CHOKE COM MODE QUAD SM 120pF 120pF 120pF 120pF I=10mA AES_CH1-2+_IN AES_CH1-2-_IN DA700204 AES_CH3-4+_IN UAM26C32CD-S AES_CH3-4-_IN 0.1uF AES_CH5-6+_IN UAM26C32CD-S 0.1uF C113 2.5K AES_CH5-6-_IN...
  • Page 33 CPi2000 Service Manual Version A - 01/19 C118 C120 C103 C104 0.1uF 0.1uF 10uF 10uF VD_FILT VD_FILT DGND DGND AES0_IN C157 AES1_IN C162 0.01uF 0.01uF AES0_IN RX0/RXP0 RX0/RXP0 AES1_IN RX1/RXN0 OSCLK1 RX1/RXN0 OSCLK1 BICLK_INNER BICLK_INNER R100 RX2/RXP1 OLRCK1 RX2/RXP1 OLRCK1 LRCLK_INNER LRCLK_INNER RX3/RXN1...
  • Page 34 CPi2000 Service Manual Version A - 01/19 SHARC SDRAM SHARC POWER SH_SDRAM +3.3V ADSP-21489KSWZ ADSP-21489KSWZ SH_A0 R271 R282 SH_D0 VDD_A AGND ADDR0 DATA0 SH_A1 R272 R283 SH_D1 ADDR1 DATA1 SH_A2 R273 R284 SH_D2 SH_A0 VDD_EXT1 GND1 ADDR2 DATA2 SH_A3 R274 R285 SH_D3 VDD_EXT2...
  • Page 35 CPi2000 Service Manual Version A - 01/19 AMP /PS MODULE +12V +12V_IN LCD_A0_A5 C144 +5V_IN LCD_RESET_A5 0.1uF 10uF LCD_CS_A5 LCD_BACKLIGHT_PWR MCU_UART_TX MCU_UART_RX UI_RESET CODEC3_SDOUT UI_GPIO0 UI_GPIO1 MCLK_EXT RTC_CE C147 MUTE LRCLK_EXT 0.1uF FAULT_CS 22uF MAIN_POWER_DET BICLK_EXT BACK_POWER_DET CODEC3_SDIN1 SPI1_SPCK_EXT CODEC2_SDOUT SPI1_MISO_EXT CODEC2_SDIN2 SPI1_MOSI_EXT...
  • Page 36 CPi2000 Service Manual Version A - 01/19 ATSAMA5D31A-CU DDR_A[0:6] DDR_A0 DDR_A0 DDR_A1 DDR_A1 DDR_A2 DDR_A2 DDR_A3 DDR_A3 DDR_A4 DDR_A4 DDR_A5 DDR_A5 LPDDR2 DDR_A6 DDR_A6 32Mx32 DDR_A7 DDR_A8 DDR_A9 DDR_A10 DDR_A11 DDR_A12 DDR_D[0:31] DDR_D0 DDR_RAS DDR_A13 DDR_D[0:31] DDR_D1 DDR_CAS DDR_D0 DDR_D2 DDR_D0 DDR_WE DDR_D1...
  • Page 37 CPi2000 Service Manual Version A - 01/19 +3.3V +1.8V LPDDR2 0.1uF +1.2V C251 C252 0.1uF 0.1uF VSS1 VDD1_1 C268 C269 C270 C271 0.1uF 0.1uF 0.1uF 0.1uF VSS2 VDD1_2 VSS3 VDD1_3 VSS4 VDD1_4 +1.2V VSS5 VSS6 VDD2_1 VSS7 VDD2_2 C277 C276 C272 C273 C274...
  • Page 38 CPi2000 Service Manual Version A - 01/19 +1.8V +1.2V +1.8V Supply (600mA Max) +3.3V 1.2V Supply (600mA Max) MPM3805GQB-Z +3.3V OUT1 MPM3805GQB-Z C334 OUT2 10uF +3.3V OUT_S OUT1 C335 C337 6.3V R139 10uF 0.01uF OUT2 C333 R239 6.3V 10uF OUT_S C331 C332 C336...
  • Page 39 CPi2000 Service Manual Version A - 01/19 JTAG SEL H= JTAG L= ICE +3.3V Interal PD ATSAMA5D31A-CU JTAG C167 R160 R166 R168 R169 100K 100K 100K 100K JTAGSEL TDI/SWD SWDIO TMS/SWDIO TCK/SWCLK SWCLK R237 NTRST R238 JTDO NRST JTDI UC_RST R140 +3.3V JTRST...

  • Page 40: Serial Flash

    CPi2000 Service Manual Version A - 01/19 ATSAMA5D31A-CU PE0/A0/NBS0 P13 PE1_A1 PE2/A2 PE3/A3 PE4/A4 PE5/A5 PE6/A6 PE7/A7 PE8/A8 2GB NAND FLASH PE9/A9 PE10/A10 PE11/A11 PE12/A12 +1.8V +1.8V PE13/A13 PE14/A14 PE15/A15/SCK3 PE16/A16/CTS3 PE17/A17/RTS3 R176 R172 PE18/A18/RXD3 PE19/A19/TXD3 100K 100K PE20/A20/SCK2 PE21/A21//NANDALE NANDALE M_EBID[0:7] PE22/A22//NANDCLE...
  • Page 41 CPi2000 Service Manual Version A - 01/19 BANK A BANK B ATSAMA5D31A-CU ATSAMA5D31A-CU E3 PA0/LCDDAT0 T2 PB0/GTX0/PWMH0 PA1/LCDDAT1 PB1/GTX1/PWML0 PA2/LCDDAT2 PB2/GTX2/TK1 +3.3V PA3/LCDDAT3 PB3/GTX3/TF1 PA4/LCDDAT4 PB4/GRX0/PWMH1 PA5/LCDDAT5 PB5/GRX1/PWML1 PA6/LCDDAT6 PB6/GRX2/TD1 PA7/LCDDAT7 PB7/GRX3/RK1 R268 R269 CODEC0_CS PA8/LCDDAT8 PB8/GTXCK/PWMH2 CODEC1_CS PA9/LCDDAT9 PB9/GTXEN/PWML2 CODEC2_CS PA10/LCDDAT10 PB10/GTXER/RF1...
  • Page 42 DATE RoHS COMPLIANCE WITH THE FIRST ARTICLE. 5079222 FID10 FID12 ENGINEER EvanZhong 20DEC2017 PROPRIETARY AND CONFIDENTIAL PROPERTY OF HARMAN. DO NOT DISCLOSE, REPRODUCE, OR SCALE SCH DOC NO. PCB PART NO. SHEET PUBLISH WITHOUT APPROVAL. NONE 1000290882 5079224 1 OF 3...

  • Page 43: Usb Interface

    CPi2000 Service Manual Version A - 01/19 +3.3V MICRO-CONTROLLER +3.3V +3.3V DS15 +3.3V MICRO JTAG 39.2 39.2 RED 0603 SYSC2 SYSC2 PA0/PGMEN0 PB0/AD4 SYSC1 39.2 SYSC1 PA1/PGMEN1 PB1/AD5 MTSW-102 LCD_SPCK 39.2 39.2 LCD_SPCK PA2/PGMEN2 PB2/AD6 UI_UART_RX LCD_RESET 39.2 39.2 LCD_RESET PB3/AD7 UI_UART_TX 100k...
  • Page 44 CPi2000 Service Manual Version A - 01/19 COL2 COL2 +3.3V BAV70 COL1 COL1 BAV70 U74HC165-S 0.1uF DGND DGND RUBBER_2MMX4 49.9K GND1 RUBBER_2MMX4 GND2 SW440119 DGND DGND +3.3V RUBBER_2MMX4 49.9K UI_CS UI_CS RUBBER_2MMX4 UI_CS UI_CS 74AHCU04 DGND +3.3V COL1 COL1 COL2 COL2 UI_CS UI_CS...
  • Page 45 CPi2000 Service Manual Version A - 01/19 Bill of Materials - CPi2000 Bill of Materials Ref ID Description CPI2000-CH CPi2000,CINEMA PROCESSOR,CH,100-240V 36-0123 CBL,PCRD,AC CHINA,2.5M,CCC APVD 5069500 PCB,ASY,CPi2000,AV1 141937-1 CON, RCA F 2P BRT TH VRT 32-0219 CON JACK XLR RA PC LATCH AA SERIES N 44-0064 SW DPST PWR PUSH-PUSH 8A 250V 5018349...
  • Page 46 CPi2000 Service Manual Version A - 01/19 Ref ID Description 5009346 CON,SKT,RJ45,10/100,1x1,TAB-UP,w/LED 5021803 CON,DSUB,RIGHT ANGLE,FEMALE 25PIN,PTH 5059488 CON,FPC,F,70P,ZIF,LCH,HOR,SM 5064686 CON,HDR,3PIN,1X3,2.54MM,VR,MALE,SM 5064687 CON,HDR,10PIN,2X5,1.27MM,VR,MALE,SM 5067185 CON,USB,MICRO,I/O,TYPE B,VERT,RCPT,2.3MM TAIL 5100515-00 IC,PROG,CPI2000 DPU,FLASH,SPI,64Mb,SO8W 5100516-00 IC,PROG,CPI2000 DPU,NAND FLASH,2G,x8,63-VFBGA 5094032-00 MECHASY,PCBA,CPI2000 UI 5079222 PCB,ASY,CPi2000_UI,AV1 32-1013 CON,HDR,1X2,2.54mm,VERT,ML 32-1055 CON,HDR,2X10,2.54mm,VERT,ML 44-0119...
