Becker CentronicPLUS LC120 PLUS Assembly And Operating Instructions Manual

Flush-mounted radio receiver for lighting systems
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CentronicPLUS
LC120 PLUS
Assembly and Operating Instructions
en
Flush-mounted radio receiver for lighting
systems
Important information for:
• Fitters / • Electricians / • Users
Please forward accordingly!
These instructions must be kept safe for future reference.
4036 630 162 0c     02/09/2022
Becker-Antriebe GmbH
Friedrich-Ebert-Straße 2-4
35764 Sinn/Germany
www.becker-antriebe.com

Advertisement

Table of Contents
loading

Related Manuals for Becker CentronicPLUS LC120 PLUS

Summary of Contents for Becker CentronicPLUS LC120 PLUS

  • Page 1 Flush-mounted radio receiver for lighting systems Important information for: • Fitters / • Electricians / • Users Please forward accordingly! These instructions must be kept safe for future reference. 4036 630 162 0c     02/09/2022     Becker-Antriebe GmbH Friedrich-Ebert-Straße 2-4 35764 Sinn/Germany www.becker-antriebe.com...

  • Page 2: Table Of Contents

    Table of contents General .................... 3 Licensing information for open source software..........  4 Warranty .................... 4 Safety instructions ...................  5 Intended use ...................  6 Explanation of displays and buttons ............ 7 Explanation of functions ................ 8 Wiring .....................  9 Compatible Centronic transmitters ............ 10 Switching between operating modes ............ 11 Resetting the operating mode .............. 12 Commissioning with a CentronicPLUS transmitter ........ 13...

  • Page 3: General

    General The radio receiver, delivered ex works, converts radio signals into control sig- nals. A lighting system can be remotely controlled using the radio receiver. The radio receiver can be controlled with all transmitters in the CentronicPLUS range of control units and various transmitters in the Centronic range (see Compatible Centronic transmitters [} 10]).

  • Page 4: Licensing Information For Open Source Software

    Written request for the licence texts: Becker-Antriebe will, on request, provide the licence texts for the licensed software being used at cost price, either on a USB stick or a similar data car- rier. Please send an email to the following email address for more information: licenses@becker‑antriebe.com...

  • Page 5: Safety Instructions

    Safety instructions The following safety instructions and warnings are intended to avert hazards and to prevent property damage and personal injury. General information • Always comply with the regulations of local energy supply companies as well as the VDE 100 provisions for wet and damp rooms during installa- tion.

  • Page 6: Intended Use

    Intended use The radio receiver described in these instructions must only be used for the operation of lighting systems. • Please note that radio-controlled systems may not be used in areas with a high risk of interference (e.g. hospitals, airports). •...

  • Page 7: Explanation Of Displays And Buttons

    Explanation of displays and buttons 1 Programming button 2 Connecting terminals 3 Mode button Switching actuator (factory set- ting) Impulse (1s) Staircase light 7 - en...

  • Page 8: Explanation Of Functions

    Explanation of functions Output Connect the lighting system as shown in the wiring diagram. Individual input This connecting terminal is intended for an additional pushbutton (normally open contact) or switch. The lighting system is switched in the following sequence: ON-OFF-ON-OFF. 8 - en...

  • Page 9: Wiring

    Wiring Caution • Risk of injury due to electric shock. • Connection may only be performed by a qualified electri- cian! • The device only offers back-of-hand protection, not touch protection. • Always take into account the device switching current. 1.

  • Page 10: Compatible Centronic Transmitters

    All CentronicPlus receivers can be operated with the Centronic transmitters listed in the Centronic/CentronicPlus compatibility table at www.becker-antriebe.com/downloads As two fundamentally different radio technologies are linked in this case, the full performance of the CentronicPlus radio control system is not available in this combination.

  • Page 11: Switching Between Operating Modes

    Switching between operating modes The programmed transmitter and installation data are de- leted when changing operating mode. Briefly pressing the mode button on the radio re- ceiver causes the adjacent LED to flash orange to indicate the current operating mode. ►...

  • Page 12: Resetting The Operating Mode

    Resetting the operating mode The staircase light time, programmed transmitter and install- ation data are deleted when resetting the operating mode. Press the mode button until the adjacent LED starts to flash red and then lights up green. Re- lease the button as soon as the LED lights up green.

  • Page 13: Commissioning With A Centronicplus Transmitter

    Commissioning with a CentronicPLUS transmitter Explanation of symbols Explanation of symbols Up/retract button (ON) STOP button (OFF) Down/extend button (ON) Programming button (on the transmitter) Programming button (on the radio receiver) Mode button (on the radio receiver) LED ring on the transmitter (only when using a CentronicPLUS transmitter.

  • Page 14: Programming The Centronicplus Transmitter

    Programming the CentronicPLUS transmitter Caution • Risk of injury due to electric shock. • Connection may only be performed by a qualified electri- cian! • The device only offers back-of-hand protection, not touch protection. Establish programming mode Make sure that the required operating mode is selected. Putting the radio receiver into programming mode by switching on the power Switch on the power.
  • Page 15 With brand new products, devices from another installation or products that have been restored to factory settings, pro- gramming mode must be established beforehand (see Estab- lishing programming mode). Bring the transmitter as close as possible to the receiver to be programmed. Press the programming button for 3 seconds when it is ready to program.
  • Page 16 Select the desired channel by pressing the func- tion key on the multi-channel hand-held transmit- ter. Press the STOP button to change the assignment status of the selected receiver. If the receiver is not yet part of the installation, it will be added and assigned to the selected channel.

  • Page 17: Selection Of The Receiver For The Setting Mode

    Selection of the receiver for the setting mode Bring the transmitter as close as possible to the required receiver. Press the programming button for 3 seconds. The transmitter performs a search and the LED ring continuously changes colour. The transmitter then switches to receiver selection and selects the re- ceiver with the best connection quality.
  • Page 18 Briefly press the programming button to change to the setting mode. ▻ The receiver confirms. ▻ The LED ring of the transmitter slowly pulses light blue. ► The setting mode is now active.   If a receiver has not yet been added to the installation (LED ring lights up yellow), it will not be possible to select it in this way.

  • Page 19: Adding Additional Transmitters To The Installation

    Adding additional transmitters to the installation If installation data already exists for the transmitter being programmed, the procedure will be terminated. Termination is indicated by the red flashing of the LED ring. In this case, the transmitter will need to be restored to factory settings (see corresponding transmitter instructions).

  • Page 20: Setting The Staircase Light Time

    Setting the staircase light time The staircase light operating mode must be set. A time of between 1 second and 10 minutes can be set as the stair- case light time. Select the required receiver as described in the chapter Selection of the receiver for the setting mode [} 17].

  • Page 21: Restoring The Factory-Set Staircase Light Time (3 Min.)

    Restoring the factory-set staircase light time (3 min.) Select the required receiver as described in the chapter Selection of the receiver for the setting mode [} 17]. First press the programming button and, within 1 second, press the STOP button at the same time and hold both buttons down for 10 seconds.

  • Page 22: Commissioning With A Centronic Transmitter

    Commissioning with a Centronic transmitter Explanation of symbols Explanation of symbols Up/retract button (ON) STOP button (OFF) Down/extend button (ON) Programming button (on the transmitter) Programming button (on the radio receiver) Mode button (on the radio receiver) Receiver confirms once or multiple times by switching the outputs or by the mode LED illu- minating Programming the Centronic transmitter...
  • Page 23 Putting the radio receiver into programming mode Putting the radio receiver into programming mode by switching on the power Switch on the power. ▻ The LED next to the programming but- ton flashes green. ▻ The receiver confirms. ► The radio receiver remains in programming mode for 3 minutes.
  • Page 24 Press the programming button of the transmitter for 3 seconds whilst in programming mode. ▻ The receiver confirms. ► Programming is now complete. Programming additional transmitters In addition to the master transmitter, up to 15 further trans- mitters (of which a maximum of three can be sensors) can be programmed in the radio receiver.

  • Page 25: Deleting Transmitters

    Deleting transmitters Deleting individual transmitters The programmed master transmitter cannot be deleted. It can only be overwritten (see Overwriting the master [} 26]). Press the programming button on the master transmitter for 3 seconds. ▻ The receiver confirms. Now press the programming button of the trans- mitter to be deleted for 3 seconds.

  • Page 26: Overwriting The Master

    Deleting all transmitters (except the master transmitter) Press the programming button on the master transmitter for 3 seconds. ▻ The receiver confirms. Re-press the programming button on the master transmitter for 3 seconds. ▻ The receiver confirms. Re-press the programming button on the master transmitter for 10 seconds.
  • Page 27 Switch off the power supply to the radio receiver. Switch the power supply to the radio receiver back on after 10 seconds. ▻ The receiver confirms. ▻ The receiver goes into the program- ming mode for 3 minutes. Now press the programming button of the new master transmitter for 10 seconds.

  • Page 28: Setting The Staircase Light Time

    Setting the staircase light time The staircase light operating mode must be set. A time of between 1 second and 10 minutes can be set as the stair- case light time. First press the programming button and, within 1 second, press the button at the same time and hold both buttons down for 3 seconds.

  • Page 29: Additional Functions With Centronicplus / Centronic

    Programming the switching times This function is available with all CentronicPlus EasyControl transmitters and with Centronic devices only if equipped with "MemoControl" transmitters from the Becker range of con- trol units. This receiver can save a switching time for one (On) and one (Off) time.

  • Page 30: Deleting The Switching Times With A Centronicplus Transmitter

    Deleting the switching times with a CentronicPLUS transmitter When deleting, both switching times are always deleted. Press the STOP button for 10 seconds. ▻ The receiver confirms. ▻ The transmitter confirms with red pulsing of the LED ring. ► The switching times are now deleted. Deleting the switching times with a Centronic transmitter When deleting, both switching times are always deleted.

  • Page 31: Activating / Deactivating The Switching Times With A Centronicplus Transmitter

    Activating / deactivating the switching times with a Centronic transmitter This function is only available with MemoControl transmitters from the Becker Centronic range of control units. The Memo function is activated and deactivated via the slide switch. The last changeover to be performed is valid.

  • Page 32: Restoring The Factory Settings For The Radio Programming

    Restoring the factory settings for the radio programming When resetting the radio programming, all programmed transmitters and installation data for CentronicPLUS, Centronic and the sensors will be deleted. Settings required for the particular operating mode will remain in place. Press the programming button until the adjacent LED starts to flash red and then lights up green.

  • Page 33: Technical Data

    Technical data Rated voltage 110-240 V AC/50-60 Hz Switching current µ 3A/110-240 V AC Degree of protection IP 20 Class of protection (dependent on correct assembly) Permissible ambient temperature -25 to +50°C Light running time Unlimited Impulse running time Staircase light running time 1s to 10 mins (factory setting: 3 min.) Type of mounting...

  • Page 34: What To Do If

    What to do if...? Problem Remedy Receiver is not responding. Insert a new battery/batteries into the hand-held transmitter. Make sure the battery/batteries is/ are correctly inserted in the hand- held transmitter. Reduce distance from receiver. Program transmitter. Check the receiver. LED ring flashes yellow or red 4 Insert new batteries into the trans- times.

  • Page 35: Simplified Eu Declaration Of Conformity

    Simplified EU declaration of conformity Becker-Antriebe GmbH hereby declares that this radio control system com- plies with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following web address: www.becker-antriebe.com/ce...
