E F F E C T I V E : A P R I L 2 0 2 3
N E W T O N S M A R T
S H A D E S Y S T E M
Q U I C K P R O G R A M M I N G
I N S T R U C T I O N S
I n c l u d e s c o n t r o l f e a t u r e s & u s e r p r o g r a m m i n g
s te p s f o r b o t h r o m a n a n d r o l l e r s h a d e s
P L U G I N M O T O R U S I N G C H A R G I N G K I T. T H I S W I L L W A K E U P T H E M O T O R .
1 C h a n n e l R e m o te
For single shade
Channel
indicator
Up
Center
(stop/favorite)
Down
Pair
button
R E C H A R G E T H E B AT T E R Y
To charge the shade, connect it to a standard USB-C 5V power supply
via a USB-C cable.
B a t te r y I s E m p t y
When the LED light flashes
red during operation, battery
needs to be recharged.
I M P O R TA N T
5 C h a n n e l R e m o te
For 2-4 shades
(4 shades / 1 all)
Channel
indicator
Up
Center
(stop/favorite)
Left
Right
Down
Channel
Selection
Pair
button
B a t te r y I s C h a r g i n g
Use a USB-C cable to charge
the motor. When the LED light
flashes green, battery is charging.
t f 8 8 8 . 5 8 2 . 8 7 8 0 | h a r t m a n n f o r b e s . c o m
t f 8 8 8 . 5 8 2 . 8 7 8 0 | h a r t m a n n f o r b e s . c o m
© 2 0 2 3 H A R T M A N N & F O R B E S , I N C . 4 . 2 3
1
H
F
A U T O M A T I O N
USB-C charging port
LED (Battery/Reset indicator)
End position button
Reset/Program button
Pull control
15 C h a n n e l R e m o te
For 5-14 shades
(14 shades / 1 all)
Channel
indicator
Up
Center
(stop/favorite)
Right
Left
Down
Previous
Next
Channel
Channel
B a t te r y I s C h a r g e d
When the LED light is constantly
green; no longer flashing, the
battery is fully charged.
Pair
button
