User Manual
Manuel de l'utilisateur
Manual del Usuario
The Installers Choice
SCL0 9
FULL MOTION FLAT PANEL TV MOUNT
SUPPORT ARTICULÉ POUR TV D'ÉCRAN PLAT
MONTAJE DE TV DE PANTALLA PLANA DE
MOVIMIENTO TOTAL
200x100
-
+15°/−5°
700x500
150 lb
40" - 90"
±88°
(68 kg)
10-71 cm
VESA
COMPLIANT
Supporting your digital lifestyle ™
Supportant votre mode de vie digital™
www.suremount.co.nz
Apoyo a su estilo de vida digital™
The Installers Choice
Advertisement
Related Manuals for Suremount SCL09
Summary of Contents for Suremount SCL09
- Page 1 MONTAJE DE TV DE PANTALLA PLANA DE MOVIMIENTO TOTAL 200x100 +15°/−5° 700x500 150 lb 40” - 90” ±88° (68 kg) 10-71 cm VESA COMPLIANT Supporting your digital lifestyle ™ Supportant votre mode de vie digital™ www.suremount.co.nz Apoyo a su estilo de vida digital™ The Installers Choice...
- Page 2 Supplied Parts and Hardware Matériel et les pièces fournies Partes suministradas y materiales B: M4 x 30mm D: M5 x 30mm A: M4 x 15mm C: M5 x 15mm E: M6 x 15mm F: M6 x 30mm G: M8 x 15mm H: M8 x 30mm I: M8 x 40mm J: 14mm Spacer...
- Page 3 WARNING/ AVERTISSEMENT/ PRECAUCIÓN Do not lay the TV face down on its front. Lean against a wall or use a TV stand. Ne posez pas la téléviseur sur son front. Restez contre un mur ou utilisez un stand de TV. No deje el televisor posado sobre su cara de cristal.
- Page 4 Wood Stud Wall/ Mur de Montants en Bois/ Pared de vigas de madera Brick or Concrete/ Brique ou Béton/ Ladrillo u Hormigón 65mm 90mm 14.5mm 6.5mm Anchor/Ancrage/Anclaje (P): CAUTION Make sure the concrete or brick wall is at least 3.5” thick. Make sure the anchor is seated completely flush with the concrete surface even if there is another layer of material, such as drywall.
