Aervoe Max Burton 6951 Operating Instructions

Max Burton
IMPORTANT SAFEGUARDS
• Read all instructions before operating
• Do not immerse cord or unit in water or other liquids
• To avoid electric shock or injury do not use for anything other than
its intended use
• Do not use without the fan blade guard in place or with loose fan
blades, or parts.
• Keep fingers and other objects away from fan blades
• Do not install where fan would obstruct safe vehicle operation or
visibility
• Never install on or near vehicle air bags
• Unplug when not in use
• Administer close supervision when using around children
PARTS IDENTIFICATION
Fan Blade Guard
Mounting Clamp
Keyhole Mount
12-Volt Plug
Turbo Fan #6951
®
Airflow Direction Adjustment
Angle Adjustment
Position Adjustment Screws
Variable Speed Dial
MOUNTING
There are two mounting options available.
1. Use the spring MoUNTiNg ClAMp to attach to the dashboard or
other secure structure.
2. Attach more permanently to a horizontal or vertical surface driving
a screw into a secure surface and attaching using the keyhole
MoUNTiNg hole.
3. Adjust to the desired position using the
sCRews.
4. Airflow may be adjusted by raising or lowering the
DiReCTioN ADjUsTMeNT lever.
CAUTION: for safety, the fan should be mounted 2-3 feet from the
driver and passengers.
OPERATION
1. Make sure the fan is attached using either of the two methods
above.
2. plug the 12-V DC plug into any 12-V power receptacle or cigarette
lighter.
3. Use the Variable Speed Dial on the 12V plug to adjust the airflow
speed to your comfort level
4. The fan may be used with our 200 watt Converter #6993 to allow
it to plug into any 120V electrical outlet. Available from your local
retailer or www.aervoe.com.
CLEANING
Unplug the fan from the 12-volt power receptacle before cleaning.
Dust with a soft cloth or other dusting item. Use a damp rag to clean
tougher dirt or grime as needed. Do not submerge any part of the fan.
CAUTION: if the fan blade guard was removed for cleaning, ensure it
is properly re-attached before using again.
TROUBLESHOOTING
if the 12-volt circuit fails to operate, try the following suggestions:
1. Unplug from the power supply an make sure that the receptacle is
clean. Do NoT Use MeTAl Tools. if cleaning is needed, use
only insulators, such as wood.
2. Check the plug's fuse. Carefully unscrew the plug's top section.
Remove and check the fuse with the proper electronic meter. if
defective, replace with correct fuse (see specification for type).
Also check the vehicle's fuse panel.
3. some cigarette lighters have a separate circuit breaker located
directly behind the cigarette lighter receptacle. if you lighter
is not working, this circuit breaker may have blown and could
require replacement. Consult your vehicle owner's manual for
replacement.
posiTioN ADjUsTMeNT
AiRflow
