Aervoe Max Burton 6952 Operating Instructions

Max Burton Deluxe Metal Fan #6952
®

IMPORTANT SAFEGUARDS

• Read all instructions before operating
• Do not immerse cord or unit in water or other liquids
• To avoid electric shock or injury do not use for anything other
than its intended use
• Do not use without the fan blade guard in place or with loose
fan blades, or parts.
• Keep fingers and other objects away from fan blades
• Do not install where fan would obstruct safe vehicle
operation or visibility
• Never instal on or near vehicle air bags
• Unplug when not in use
• Administer close supervision when using around children

PARTS IDENTIFICATION

Fan Blades
Mounting Bracket
with Screw Holes
Fan Blade Guards
Swivel & Tilt Adjustment
Power & Speed Switch:
High/Off/Low

MOUNTING

1. Place the black rubber ring on the desired mounting surface
2. Place the fan base on top of the rubber ring
3. Drill three holes using the screw holes as guides
4. Use the three supplied screws to attach the fan to the
mounting surface

OPERATION

1. Plug the 12-V DC plug into any 12-V power receptacle or
cigarette lighter. The LED indicator light will illuminate.
2. Select either
position is the oFF position.
3. The fan may be used with our 200 watt Converter #6993 to
allow it to plug into any 120V electrical outlet. Available from
your local retailer or www.aervoe.com.

CLEANING

Unplug the fan from the 12-volt power receptacle before
cleaning. Dust with a soft cloth or other dusting item
damp rag to clean tougher dirt or grime as needed. Do not
submerge any part of the fan.
CAUTION: if the fan blade guard was removed for cleaning,
ensure it is properly re-attached before using again.

TROUBLESHOOTING

if the 12-volt circuit fails to operate, try the following
suggestions:
1. Unplug from the power supply an make sure that the
receptacle is clean. Do NoT USE METAL TooLS. if
cleaning is needed, use only insulators, such as wood.
12-Volt Plug 2. Check the plug's fuse. Carefully unscrew the plug's top
section. Remove and check the fuse with the proper
electronic meter. if defective, replace with correct fuse (see
specification for type). Also check the vehicle's fuse panel.
3. Some cigarette lighters have a separate circuit breaker
located directly behind the cigarette lighter receptacle. if you
lighter is not working, this circuit breaker may have blown
and could require replacement. Consult your vehicle owner's
manual for replacement.
HigH or Low SPEED operation. The center
Use a
.
