HDI Edge Series Quick Start Manual

HDi Multi-touch Screen Quick Start Guide - HDi Edge Series Android 8.0
The instructions below have been created to help you get started with your new HDi multi-touch screen. This document assumes a basic knowledge of computers and hardware. If
you require more detail, please don't hesitate to contact us at info@hdinteractive.com.au.

Multi-touch Screen and Laptop set-up

1. Cables

Supplied with your multi-touch screen are various 2 metre cables.
USB A to B cable
A
B
HDMI cable

2. Rear panel

HDMI OUTPUT (Connect additional
monitor)
HDMI
(HDMI 1 Input Source)
TOUCH USB (Interactivity)
B
LAN IN DP TOUCH USB HDMI 1

3. Front panel

B
Touch USB
USB (Type - C)
TOUCH USB
(Interactivity)
HDMI
(HDMI 3 Input Source)
HDMI 2 VGA VGA AUDIO USB 1
HDMI 3 USB 3.0 PC MEDIA
USB
(Android USB)
PC
(USB PC)
HDMI OUT
SD CARD
HEADPHONE
AV OUT
YPbPr
AV IN
USB 2
