Process Point:
Programming
Assembly data
Production line
Product
Assembly stage
Issue Date
1 Unpack the Fujitsu SBC (AE8214) from the bag and keep the bag for later
2 Fit the RAM(AE8229) into the SBC
3 Get and fit a programmed Flash card (with
the Fujitsu sticker) in to the SB
SWITCH
4 Plug up the SBC as shown in the picture below
5 Ensure that the power supply is on
6 Press the start-up switch on the little screen as shown and
the SBC should start to boot. You should hear a beep.
7 Quickly after you have powered up the SBC hold down F2
to enter the BIOS Setup
iLiveSeries
ilive SBC Fujitsu 004-111
Programming
22/07/11
TFT
ALLEN&HEATH
VGA
MONITOR
KEYBOARD
POWER
AH-M0264
Page 1/2
Advertisement
Table of Contents
Related Manuals for ALLEN & HEATH iLive Series
Summary of Contents for ALLEN & HEATH iLive Series
- Page 1 Process Point: ALLEN&HEATH Programming AH-M0264 Assembly data Production line iLiveSeries Product ilive SBC Fujitsu 004-111 Assembly stage Programming Issue Date 22/07/11 1 Unpack the Fujitsu SBC (AE8214) from the bag and keep the bag for later 2 Fit the RAM(AE8229) into the SBC 3 Get and fit a programmed Flash card (with the Fujitsu sticker) in to the SB SWITCH...
- Page 2 Process Point: ALLEN&HEATH Programming AH-M0264 Assembly data Production line iLiveSeries Product ilive SBC Fujitsu 004-111 Assembly stage Programming Issue Date 22/07/11 8 Use the arrows keys to move across the menu bar and select Main. 9 Select Boot features 10 Check/Change the Keyboard Check to [Disable] 11 Now press Esc to go back to the Main page 12 Use the arrows keys to move across the menu bar and select Advanced 13 Select Peripheral Configuration...
