- Page 1 MANUAL MODEL WW3 & WW4 FOR CANON MEDICAL Revision: 00 Effective Date: 17 October 2022...
-
Page 2: Table Of Contents
Table of Contents Haskris Contact Information ................. 4 Installation: Confirm MRI and Heat Exchanger Model MRI Model ...................... 5 Heat Exchanger Model ..................5 III. Installation: Mounting, Clearances, Connections Mounting ......................6 Clearances ...................... 7 Connections ....................8 Installation: Electrical, Connection to Outdoor Chiller Electrical ...................... - Page 3 Units of Measure ................... 21 Faults ......................22 Heat Exchanger Features City Water Backup ..................24 Local Monitoring ................... 25 Maintenance Frequency ....................26 Water Quality ....................26 Electrical Inspection ..................26 Phone: 001 847 956 6420 Page 3 of 26 Email: service@haskris.com...
-
Page 4: Haskris Contact Information
I. Haskris Contact Information Contact Haskris with any questions about a unit and/or the information in this manual. Haskris has a team of engineers available to answer questions, troubleshoot issues, or provide supplemental information as needed. Phone: 001 847 956 6420 Email: service@haskris.com... -
Page 5: Installation: Confirm Mri And Heat Exchanger Model
Heat Exchanger Model Instructions: There are several different heat exchanger models for cooling Canon MRIs. Use the MRI information to identify the appropriate heat exchanger model. These instructions include details for the two Haskris models. Canon MRI Model Haskris Heat Exchanger Model... -
Page 6: Installation: Mounting, Clearances, Connections Mounting
• The WW is designed to be floor mounted with rear of the unit secured to a wall. Adjustable leveling legs are included. Use of the leveling legs is optional. • Secure to wall through wall mount brackets in two locations. WW4 front view showing wall-mount brackets Phone: 001 847 956 6420 Page 6 of 26 Email: service@haskris.com... -
Page 7: Clearances
• Maintain a clearance of 18” (46cm) on the sides and top for water/electrical connections and access to the reservoir. • Maintain a clearance of 36” (92cm) on the front for routine operation and maintenance. Phone: 001 847 956 6420 Page 7 of 26 Email: service@haskris.com... -
Page 8: Connections
(2) IN THE EVENT OF POWER LOSS OR CHILLER FAILURE CITY WATER WILL PROVIDE COOLING TO THE REFRIGERATOR COMP CIRCUIT ONLY. WHEN IN CITY WATER BYPASS THE DRAIN MUST BE OPEN. (3) RF CIRCUIT IS NOT APPLICABLE TO WW3 MODEL Phone: 001 847 956 6420... - Page 9 WW3 side view WW3 top view Phone: 001 847 956 6420 Page 9 of 26 Email: service@haskris.com...
- Page 10 WW4 side view WW4 top view Phone: 001 847 956 6420 Page 10 of 26 Email: service@haskris.com...
-
Page 11: Installation: Electrical, Connection To Outdoor Chiller
• Do not mount or support any electrical service disconnect directly to the heat exchanger. Electrical connection: Use a dedicated service disconnect and time delay fusing. Connect incoming electrical to the distribution block in the electrical box. Distribution Block Phone: 001 847 956 6420 Page 11 of 26 Email: service@haskris.com... -
Page 12: Connection To Outdoor Chiller
Connection to Outdoor Chiller Purpose: Some heat exchanger systems come with a Haskris outdoor chiller. For these systems, the heat exchanger must be wired to the chiller to ensure that Haskris will get remote notifications of heat exchanger faults. Installation: A 150ft (45.7m) cable is provided for this connection. Connect the provided cable to the orange terminal strip in the chiller’s electrical box. -
Page 13: Installation: Filling The Reservoir
• Replace cap after filling. • Make sure additional drinking/spring water is on hand to top off the tank during startup when the unit’s pump fills the external piping. Phone: 001 847 956 6420 Page 13 of 26 Email: service@haskris.com... -
Page 14: Installation: Final Checks
Controller Faults Check: Press the button on the controller. The screen should say NO ALARMS. If any faults are described, consult Haskris to resolve these. Phone: 001 847 956 6420 Page 14 of 26 Email:... -
Page 15: Pre-Startup Checklist
L1-L3 Communication: ❑ Communication wiring between the WW and OPC is installed (if Haskris chiller was provided). Fluid fill: ❑ The tank is full of drinking/spring water. The tank should be filled to about 3” from the top of the tank, just below the overflow. -
Page 16: Optional Modbus Or Bacnet Communication Capability
BMS using Modbus or BACnet communication. Operation: The method of interfacing with the BMS varies depending on the specific design and whether the heat exchanger is paired with a Haskris outdoor chiller. Contact Haskris for details. Phone: 001 847 956 6420... -
Page 17: Startup
Purpose: The heat exchanger has a phase monitor to check incoming electrical power. Operation: The phase monitor is factory adjusted by Haskris according to the proper electrical settings for the heat exchanger. Do not adjust the knobs on the phase monitor without discussion and approval from Haskris. -
Page 18: On/Off Switch
OFF position (vertical). If a fault occurs, turning the switch to OFF and then back ON will reset the fault. Note that city water backup is active while switch is in the OFF position. ON/OFF switch, vertical position Phone: 001 847 956 6420 Page 18 of 26 Email: service@haskris.com... -
Page 19: Pump Priming
Pump Priming Purpose: All fluid is removed from the pump head prior to shipment from Haskris. When starting the pump, it needs to be filled with fluid. This process is called priming the pump. When the reservoir is full, the pump suction line is “flooded”. In some cases, this flooded suction will automatically prime the pump. -
Page 20: Controller Display
The site’s BMS is connected to the heat exchanger and sending it a signal to be OFF OFF by BMS City water backup is active Description of status modes Phone: 001 847 956 6420 Page 20 of 26 Email: service@haskris.com... -
Page 21: Adjusting Set Value (Sv)
7. Press the buttons to select different units of measure 8. Press the button several times to return to the main display Phone: 001 847 956 6420 Page 21 of 26 Email: service@haskris.com... -
Page 22: Faults
HH:MM DD/MM/YY Fault reset screen Fault reset: Press the button until you go past the last active fault, you will see this screen which explains how to reset faults. Phone: 001 847 956 6420 Page 22 of 26 Email: service@haskris.com... - Page 23 Supply Fluid temp is Supply water temperature Confirm primary source of cooling water (central chilled loop, outdoor above alarm setpoint rose too high chiller) is operating normally Description of common faults Phone: 001 847 956 6420 Page 23 of 26 Email: service@haskris.com...
-
Page 24: Heat Exchanger Features
OFF. If manual operation is preferred, implement a manual ball valve in the external piping at the city water inlet. Leave the manual valve closed during normal operation, and open the manual valve when city water backup is required. Phone: 001 847 956 6420 Page 24 of 26 Email: service@haskris.com... -
Page 25: Local Monitoring
Method: The heat exchanger has available potential free fault contacts on the controller. Operation: The potential free contact is the J12 terminal on the controller. There is a NO and NC contact available as needed. Potential free fault contact Phone: 001 847 956 6420 Page 25 of 26 Email: service@haskris.com... -
Page 26: Maintenance Frequency
Electrical Inspection Maintenance: Use a multimeter to check electrical values. Take measurements at contactors or terminal blocks. Compare values to the unit or component name plate. Phone: 001 847 956 6420 Page 26 of 26 Email: service@haskris.com...
