Sensor location is very specific and very important for proper function of the sauna heater.
Sensor must be 3" to the front or open side of heater (not in corner), 1" down from ceiling.
1. Using Sensor Cover: To hide cable inside wall cavity, you must first feed the sensor wire through the sensor
holder, then run wire inside the wall, down to area where heater is to be installed.
2. Sensor tip mounts to top of sensor, 1" maximum down from ceiling. Place cover over holder, making sure not to
cover sensor itself.
3. Do NOT mount sensor holder on top of sensor after the fact. (This can affect sensor reading and affect sauna
operation).
4. Many choose to install bare sensor without holder and cover. Arguably, this is optimal installation as sensor is
fully exposed to air temp, not metal (cover) and more accurately reflects air temperature.
Indoor Sauna: Position the air inlet and outlet vents as far away from one another as possible (diagonally opposite).
The outlet vent should be located high on a wall (A), and should be about 19" sq. should be directed back into house – it
should not be discharged directly to the outside.
If outlet wall is inaccessible, install outlet vent in far corner of ceiling. Duct over drop ceiling to area in front of sauna (B).
Outdoor Saunas: Outdoors generally have easy access. Some choose to hold off on vents initially and add later if it
appears to be necessary.)
Do not install inlet and outlet vents on same wall. Bad ventilation can be worse than no ventilation.

Temperature Sensor Location

Temperature Sensor Installation

SAUNA VENTILATION
