Pc Health Status - ECS Electronics L7VTM Manual

expansion card. Use the second item Reserved Memory Length to set the
amount of reserved memory. Press <Esc> to close the Memory Resources
sub-menu.
PCI/VGA Palette Snoop (Disabled)
This item is designed to overcome some problems that can be caused by
some non-standard VGA cards. This board includes a built-in VGA system that
does not require palette snooping so you must leave this item disabled.
Assign IRQ for VGA/USB (Enabled)
Names the interrupt request (IRQ) line assigned to the USB/VGA (if any) on
your system. Activity of the selected IRQ always awakens the system.

PC Health Status

On mainboards that support hardware monitoring, this item lets you monitor
the parameters for critical voltages, critical temperatures, and fan speeds.
Phoenix – AwardBIOS CMOS Setup Utility
Case Open Warning
Shutdown Temperature
CPU V-CORE
+ 2.5V
+ 3.3V
+ 5V
+ 12V
Voltage Battery
Current System Temp
Current CPU Temp
CPUFAN1
CASFAN1
↑ ↓ → ← : Move Enter : Select
F5:Previous Values
Case Open Warning (Disabled)
Enables or disables the alert warning message when the case has been
opened.
Shutdown Temperature (Disabled)
Enables you to set the maximum temperature the system can reach before
powering down.
System Component Characteristics
These fields provide you with information about the systems current operating
status. You cannot make changes to these fields.
PC Health Status
[Disabled]
[Disabled]
+/-/PU/PD:Value: F10: Save ESC: Exit F1:General Help
F6:Fail-Safe Defaults F7:Optimized Defaults
