Summary of Contents for Sinclair SF D3 Series
- Page 1 3,4-ROWS DUCT FAN COIL & OPERATION SF-XXXD3 SF-XXXD4 AIR CONDITIONING...
- Page 2 “Original instructions” IMPORTANT NOTE: Read this manual ca r efully befo r e installing or operating your new air conditioning unit. Make sure to save this manual for future reference.
-
Page 3: Table Of Contents
Install according to this installation instructions strictly. CONTENTS PAGE If installation is defective, it will cause water leakage, electrical shock and fire. PRECAUTIONS..................1 When installing the unit in a small room, take measures INSTALLATION INFORMATION..............2 against to keep refrigerant concentration from exceeding FUNCTIONS &... -
Page 4: Installation Information
2. INSTALLATION INFORMATION CAUTION To install properly, please read this "Owner’s & Installation Before installing the unit,it is necessary to check manual" at first. whether the ground wire is charged. If it is,the unit shall not be installed before correction. The air conditioner must be installed by qualified persons. -
Page 5: Parts Names
6. PARTS NAMES Precautions before installation Decide the correct way of conveying the equipment. The above figures is an instance models, which would be different from the one that you purchase. Try to transport this equipment with the original package. If the air conditioner needs to be installed on a metal part of the air return cabinet building, electric insulation must be performed, and the installation... - Page 6 Concrete iron Embedded bolt (With embedded Gasket bolt in pipe) Pendant Pendant bolt assembly Fig.7-6 Suspending the indoor unit Fig.7-4 Use tools such as pulleys to hoist the indoor unit to the pendant bolt. New concrete roughcast Use tools such as gradienter to settle the indoor unit Set it with embedded bushes or embedded bolts.
- Page 7 3-Row Duct Two pipe type (unit:mm) The quantities of the fans and motors are only for reference, please prevail in kind! B (Air return port) Electric control box Intlet Outlet Condensation Air exhaust valve water draining port 4-10X16Hoisting hole Fig.7-9.2 Four pipe type (unit:mm) The quantities of the fans and motors are only for reference, please prevail in kind! B (Air return port)
-
Page 8: Pipe Connection
9. INSTALLATING DRAINAGE PIPE NOTE Install the drain pipe of the fan coil unit The above figures is an instance models, which would be Before out from factory, the scupper adopts the pipe thread. different from the one that you purchase. NOTE The broken lines in above figures for illustrate the dimension of air return box. -
Page 9: Wiring
10. WIRING CAUTION The air conditioner should use separate power supply with rated voltage. The external power supply to the air conditioner should have ground wiring, which is linked to the ground wiring of the indoor and outdoor unit. The wiring work should be done by qualified persons according to circuit drawing. An all-pole disconnection switch having a contact separation of at least 3mm in all poles should be connected in fixed wiring. - Page 10 10.1 Wiring Diagram MOTOR1 MOTOR2 DC FAN1 DC FAN2 MAIN BOARD LED4 SW1 SW2 EARTH LED1 POWER HI MID LOW N ALARM MID LOW GREEN/YELLOW POWER IN GROUND WIRE NEUTRAL WIRE LIVE WIRE POWER IN Thermostat Owner’s & Installation manual...
- Page 11 10.2 The default model of DC fan coil is set as 12Pa when leaving the factory. Clients can dial to the responding position to choose the model and static pressure according to the nameplate and actual static pressure requirements of the models and static dial code table . Models and static dial code table : STATIC 12Pa...
- Page 12 MODE:SF-200D3 Information to identify the model(s)to which the information relation: Item Symbol Value Unit Cooling capacity(sensible) Prated,c 1.75 Cooling capacity(latent) Prated,c Heating capacity Prated,h 2.68 Total electric power input Pelec 0.017 Sound power level(per speed setting,if applicable) 50/40/33 contact details MODE:SF-300D3 Information to identify the model(s)to which the information relation: Item...
- Page 13 MODE:SF-600D3 Information to identify the model(s)to which the information relation: Item Symbol Value Unit Cooling capacity(sensible) Prated,c 4.49 Cooling capacity(latent) Prated,c 1.36 Heating capacity Prated,h 6.62 Total electric power input Pelec 0.049 Sound power level(per speed setting,if applicable) 57/49/42 contact details MODE:SF-800D3 Information to identify the model(s)to which the information relation: Item...
- Page 14 MODE:SF-200D4 Information to identify the model(s)to which the information relation: Item Symbol Value Unit Cooling capacity(sensible) Prated,c 1.374 Cooling capacity(latent) Prated,c 0.29 Heating capacity Prated,h 2.453 Total electric power input Pelec 0.017 Sound power level(per speed setting,if applicable) 51.1/41.1/38.7 contact details MODE:SF-300D4 Information to identify the model(s)to which the information relation: Item...
- Page 15 MODE:SF-600D4 Information to identify the model(s)to which the information relation: Item Symbol Value Unit Cooling capacity(sensible) Prated,c 3.601 Cooling capacity(latent) Prated,c 0.805 Heating capacity Prated,h 6.034 Total electric power input Pelec 0.05 Sound power level(per speed setting,if applicable) 59.1/52.2/43.7 contact details MODE:SF-800D4 Information to identify the model(s)to which the information relation: Item...
- Page 16 United Kingdom www.sinclair-world.com This product was manufactured in China (Made in China). R E P R E S E N T A T I V E SINCLAIR Global Group s.r.o. Purkynova 45 612 00 Brno Czech Republic T E C H N I C A L S U P P O R T SINCLAIR Global Group s.r.o.
