Summary of Contents for Thundercomm TurboX T55
- Page 1 Empowering Every IoT Device with Our Technology Thundercomm TurboX™ T55 M.2 SoftWare User Manual Rev. 1.0 November 25, 2020...
- Page 2 This document itself and the proprietary technical information contained herein is the property of Thundercomm. Without prior written authority of Thundercomm, no one shall copy, modify or reprint the whole or part of this document. Offenders are liable for all related damages, loss and litigations.
- Page 3 Thundercomm TurboX™ T55 M.2 Open Kit SW User Manual External Bus Interface JTAG Joint Test Action Group Power Management Board Global Position System AUX. Auxiliary Frequency Range 1 Frequency Range 2 Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
-
Page 4: Table Of Contents
Thundercomm TurboX™ T55 M.2 Open Kit SW User Manual Table of contents 1 Overview ............................1 1.1 TurboX T55 M.2 5G DK IO Map ........................ 1 1.2 TurboX T55 M.2 5G DK Physical Map ..................... 2 2 T55 M.2 Platform Features and Use Cases ................4 2.1 LED control .............................. -
Page 5: Overview
Thundercomm TurboX™ T55 M.2 Open Kit SW User Manual 1 Overview The T55 M.2 SOM is designed based on the SDX55 5G Modem and purpose-built for IoT applications. The T55 M.2 platform is based on Linux operating system. This document will focus on providing the usage instructions. -
Page 6: Turbox T55 M.2 5G Dk Physical Map
Thundercomm TurboX™ T55 M.2 Open Kit SW User Manual 1.2 TurboX T55 M.2 5G DK Physical Map Top View: Bottom View: Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved. - Page 7 Thundercomm TurboX™ T55 M.2 Open Kit SW User Manual Table 1-1 T55 M.2 5G DK Physical map ① LGA T55 SOM ② LGA Fan Connector ③ LGA EBI Connector ④ LGA 1G LAN ⑤ LGA Type-C ⑥ LGA WCD Connector ⑦...
-
Page 8: T55 M.2 Platform Features And Use Cases
Thundercomm TurboX™ T55 M.2 Open Kit SW User Manual 2 T55 M.2 Platform Features and Use Cases This chapter presents T55 M.2 Platform features and use cases. Please check if T55 M.2 is plugged into LGA PCIE well. Currently, ⑮ M.2_Debug_LOG is not available. If really need it, please weld M.2 and IO board with wire manually. -
Page 9: Wwan
Thundercomm TurboX™ T55 M.2 Open Kit SW User Manual 2.2 WWAN This section will introduce the function of WWAN to have access to service of NSA and SA. Before using the WWAN function, please prepare valid (U)SIM card then insert it into the main slot for (U)SIM card. - Page 10 Thundercomm TurboX™ T55 M.2 Open Kit SW User Manual Table 2-1 T55 M.2 matrix chart of Bands and Antennas Ports(FR1) Mode Bands Main Port AUX. Port n1/n2/n3/n7/n25/n38/n40/n66 SDX-ANT0 SDX-ANT1/2/3 n5/n8/n12/n14/n20/n28A/n28B SDX-ANT0 SDX-ANT1 n48/n77/n78/n79 SDX-ANT1 SDX-ANT0/2/3 SDX-ANT3 SDX-ANT0/1/2 B1/B2/B3/B4/B7/B25/B30/B34/B38/B39/B40/B41/B66 SDX-ANT0 SDX-ANT1/2/3...
- Page 11 Thundercomm TurboX™ T55 M.2 Open Kit SW User Manual Table 2-2 T55 M.2 matrix chart of Antenna Ports and Bands(FR1) Antenna Port Freq. Range Bands WCDMA: B1,B2,B3,B4,B5,B8,B9,B19 FDD-LTE: B1,B2,B3,B4,B5,B7,B8,B12,B13,B14,B17,B18,B19,B20, B25,B26,B28A,B28B,B30,B66 Main TDD-LTE: B34,B38,B39,B40,B41 617-910MHz SDL: B32 SDX-ANT0 1710-2690MHz FDD-NR: n1,n2,n3,n5,n7,n8,n12,n14,n20,n25,n28A,n28B,n66...
-
Page 12: Confirm The Status Of The Device By At Commands
Thundercomm TurboX™ T55 M.2 Open Kit SW User Manual 2.2.1 Confirm the status of the device by AT commands (1) First connect M.2_TYPE_C with Serial debugging tool ⑭ (2) Confirm network registration status through the steps as below. a. To confirm if modem can keep online status. - Page 13 Thundercomm TurboX™ T55 M.2 Open Kit SW User Manual b. To confirm if (U)SIM card can keep ready status. First enable the extended error codes to get a verbose format AT+CMEE=2 Now get the status of (U)SIM card, AT+CPIN? +CPIN: READY If (U)SIM card is ready, a response with the sign of plus for AT command request as above.
-
Page 14: Usb Ethernet Tethering
Thundercomm TurboX™ T55 M.2 Open Kit SW User Manual 2.3 USB Ethernet Tethering Use the USB cable to connect T55 M.2 Type-c port and Windows PC usb port, and also confirm WWAN antennas are properly connected. Since it is limited that LAN mode and USB cannot share the mobile data... -
Page 15: Gps
Thundercomm TurboX™ T55 M.2 Open Kit SW User Manual 2.4 GPS (1) Confirm the antenna is properly connected. (2) Disable SELinux $ adb shell ~ # setenforce 0 54.883554] audit: type=1404 audit(315964819.529:13): enforcing=0 old_enforcing=1 auid=4294967295 ses=4294967295 NOTE: Make sure the test environment is in an open place with good GPS coverage. - Page 16 Thundercomm TurboX™ T55 M.2 Open Kit SW User Manual //Type “1”, Select “loc init” Invoking qapi_Loc_Init() Location Init Success 1: loc init 2: loc deinit 3: start tracking 4: stop tracking 5: get singleshot 6: cancel singleshot 7: get best available position...
- Page 17 Thundercomm TurboX™ T55 M.2 Open Kit SW User Manual Wait for the callback to return the result. When the positioning is successful, the following result will be returned: LOC API CALLBACK : SINGLE SHOT LOC API CALLBACK : TRACKING Time(HH:MM:SS): 07:12:42 LAT: 40.30 LON: 116.35700...
