23 dBi High Gain Directional Panel Antenna for 5.8 GHz (5054-PA-23)
Pictured: SmartAnt antenna
Package Contents
Antenna
Extension Cable (50cm)
Mounting Kit
Surge Arrestor
Water-proof tape
Quick Installation Guide
Mounting
Copyright © 2006 Proxim Wireless Corporation. All rights reserved.
Tsunami MP.11 Recommended Antennas
5. Mounting base, 1 PC
6. M4*8 screw+W+S/W-4 PCS
7. Space keeper – 4 pcs
8. M-shape mounting – 1 pc
9. ¾" screw – 4 pcs
10. Plastic wallplug – 4 pcs
11. M6*16 screw – 4 pcs
12. M6 S/W – 4 pcs
13. M6 W – 4 pcs
1. Mounting base, 1 PC
2. M4*8 screw+W+S/W-4 PCS
3. Space keeper – 4 pcs
4. M-shape mounting – 1 pc
5. Pole mount clip – 1 pc
6. M6*60 screw – 2 pcs
7. M6*16 screw – 4 pcs
8. M6 S/W – 4 pcs
9. M6 W – 4 pcs
27
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Proxim 5054-PA-23
Summary of Contents for Proxim 5054-PA-23
- Page 1 Tsunami MP.11 Recommended Antennas 23 dBi High Gain Directional Panel Antenna for 5.8 GHz (5054-PA-23) Pictured: SmartAnt antenna Package Contents Antenna Extension Cable (50cm) Mounting Kit Surge Arrestor Water-proof tape Quick Installation Guide Mounting 5. Mounting base, 1 PC 6. M4*8 screw+W+S/W-4 PCS 7.
- Page 2 -40 to +80 degrees C Humidity 95% @ 25 degrees C Lightning protection DC ground Size 360 x 360 x 16 mm Weight 1.6 kgw Radome material ABS, UV resistant Radome color white Patterns Copyright © 2006 Proxim Wireless Corporation. All rights reserved.
- Page 3 Tsunami MP.11 Recommended Antennas Copyright © 2006 Proxim Wireless Corporation. All rights reserved.
