- Page 1 SPUTNIK MODULAR 5-STEP VOLTAGE SOURCE MANUAL V.1 SPUTNIK-MODULAR.COM...
-
Page 2: Table Of Contents
SPUTNIK MODULAR 5-STEP VOLTAGE SOURCE TABLE OF CONTENTS SPECIFICATIONS INSTALLATION DESCRIPTION DIAGRAM WARRANTY SPUTNIK-MODULAR.COM... -
Page 3: Specifications
SPUTNIK MODULAR 5-STEP VOLTAGE SOURCE SPECIFICATIONS FORMAT: EURORACK DIMENSIONS: 10HP, 28mm deep INTERNAL AND EXTERNAL SIGNALS (3.5mm Jacks): CV: 0-5V, AUDIO: +/-5V MAX CURRENT: +12V: 50mA -12V: 75mA +5V: 10mA SPUTNIK-MODULAR.COM... -
Page 4: Installation
SPUTNIK MODULAR 5-STEP VOLTAGE SOURCE INSTALLATION Remove module from packaging. Power down your modular synthesizer and disconnect the power cable from the wall outlet. Attach the included power cable to the module’s power connector and connect the other end to the power distribution bus in your EuroRack synthesizer case. -
Page 5: Description
SPUTNIK MODULAR 5-STEP VOLTAGE SOURCE DESCRIPTION The SPUTNIK CV PROCESSOR is a multi-functional module for manipulat- ing Eurorack control signals. It can sum, invert, attenuate, amplify control voltages, also it can add offset to CV or crossfade between two CVs. -
Page 6: Diagram
SPUTNIK MODULAR 5-STEP VOLTAGE SOURCE Each stage features a pulse The Pulser is normalized to act as a voltage controllable master clock output that is triggered when for driving stage selection like a conventional sequencer. It can also be that step or “stage” is activated. -
Page 7: Warranty
SPUTNIK MODULAR 5-STEP VOLTAGE SOURCE WARRANTY This product is covered by the Sputnik Modular warranty, for one year following the date of purchase. This warranty covers any defect in the manufacturing of this product. This warranty does not cover any damage or malfunction caused by incorrect use –...
