Eastbound MotoWinch 1707001 Operating Instructions

Content
About this manual
1. Brief Description
2. Technical Specifications
3. Safety
4. Components and application
5. First use as MotoWinch
6. Maintenance
About this manual
When text follows a marker (as shown on the left), this means that an important warning indicates that
there is a danger of injury to the user or damage to the device or the motorbike.
Note; the user is responsible for adequate and personal protection while using the MotoWinch at all
times.
1. Brief Description and disclaimer;
The MotoWinch shall only be used as described in these operating instructions. The MotoWinch is
not suitable for general lifting purposes or for applications other than those described in the operating
instructions . Using the MotoWinch implies the supplier's indemnification for damage caused by
incorrect or improper use. It is essential that user practices the use of the MotoWinch in a safe and
controlled environment. A remote area is definitely not the place where you want first test and try the
MotoWinch. The MotoWinch is a great tool but please note that for safety reasons it is advised to
never visit rough and remote areas alone on your motorcycle. Supplier will not accept any
responsibility for damages caused to motorbike or tools or any kind of bodily harm or death of user
due to incorrect use of the Eastbound MotoWinch.
2. Technical Specifications
Article nr.
Length
Gross weight
3. Safety
Avoid to come into contact with moving parts during use. Serious injury may occur. Make sure that the
strap is always rolled evenly. An unevenly rolled strap can cause blocking or damage of strap and
ratchet. Always use the rubber anti-slip foot on hard surfaces. If the surface is slippery, e.g. due to oil
leakage, moss or algae growth, there is a substantial risk that the rubber foot does not provide
sufficient stability. It is up to the user to make a safe assessment of the situation. However, during the
winching, the user must always take position such that, in case of sudden sideway slippage or failure of
the winch, the motorbike cannot fall against or on the user.
4. Components and application
Explanation of the parts;
The Ratchet;
The ratchet is a standard 3 ton or 5 ton (optional) cargo ratchet. The ratchet lever is of such size that the power required for
the various applications is limited. The ratchet must be clean when used and inspected for possible damage. The ratchet has
been pre-mounted to the MotoWinch tube with a pipe locking pin.
MotoWinch
Operating instructions
1707001
112cm
1885 gram / 2285 gram
1
1
1
1
1
1
2
4
