LIGMAN KI-60731 Installation And Service Manual

INSTALLATION AND SERVICE MANUAL
For Installation of Kios Inground uplight round dia. 220mm. and dia. 216mm. LED.
Model. KI-60731 and KI-60741
Product drawing (dimensions)
EMBOSS FRAME KI-60731
FLAT FRAME KI-60741
■ LIGMAN standard products are supplied with the control gear 220-240V 50/60Hz.
The control gear for other voltages and frequencies is available upon request, please consult us for more details.
■ LIGMAN luminaires are designed to conform IEC 60598 2-13 standard.
Technical amendments and modifications techniques reserved.
L i g m a n L i g h t i n g
Europe Headquarters
Ligman Europe s.r.o.
VGP Park Usti nad Labem, P 2
Prestanov 113
403 17 Prestanov
Czech Republic
Tel. +420 608 740 504 sales.cz@ligman.com
|
www.ligman.com
IP67 IK10 CLASS I
Drive over 2,500kg. at max. 50km/h.
1
4
Cable OD
Min 6mm.
Max 12mm.
Thailand Headquarters
Ligman Lighting Co., Ltd.
17/2 Moo 4, Monthong, Bangnampreaw
Chachoengsao 24150 Thailand
Tel : +66 (2) 7339140
info@ligman.com
M KI-60731/03/09/16/REV.2
0.5m
Ta 25°c
Glass surface temp
KI-60731 = 45.0°c
Ta 25°c
Glass surface temp
KI-60741 = 45.0°c
TOOL
2
5
20 30
6
²
CABLE SIZE : 3x1.0mm
1/2
OK
YES
NO
NO
3,4
