- Page 1 INSTALL GUIDE M L 0 8 0 Q T M A T E - C & 0 7 4 4 LCD upgrade kit FOR YOUR MODICON- PANELMATE (91-00918-03, 91-01064-00 & 91-00744-10) M20A03-080QTMATE/080QT0744...
-
Page 2: Warranty
IMPORTANT: WARRANTY Before using any MONITECH product please carefully review this Manual as well as any additional documentation provided with your shipment. Attempting any of the following will void product warranty: • unauthorized repairs or parts replacement • inappropriate use or placement: exposing product to liquids, harmful gases, electrical shock, physical shock, temperatures beyond the range of -4°F to... - Page 3 REMOVALE: Step #1) Turn off turn off main power, turn off machine. Step #2) Take out the monitor & controller from your machine by loosening all surrounding bolts. Power off your controller and monitor via switch. Unplug monitor and controller from machine. Monitor &...
- Page 4 Step #3) Make sure to take a picture of all your connections before unplugging any of your connections. Unplug your video cable and keypad cable. Keypad Connection Video Cable Step #4) Take off controller. Step #5) Take off your CRT from your machine. M20A03-080QTMATE/080QT0744...
-
Page 5: Installation
Step #7) Put front frame back on to the front bezel. Open the monitor that Monitech has supplied you. Place our monitor into opening shown the holes of the brackets should match. Use 4 bolts previously taken off the front frame to mount our monitor to the front frame. - Page 6 Step #9) Takeout MAV066A from MK105 box. Do not use any of the other cables, those cables are only for testing the monitor on a computer. Plug -in MAV066A to your controller as shown and plug-in VGA cable to Monitech monitor and plug-in power jack into Monitech monitor.
- Page 7 Step #11) If everything is alright. Turn off power to control then put front bezel with control and Monitech monitor back onto machine then turn on main power of your machine and turn on machine CNC machine and you're ready to go. If you need to adjust your screen size use our user guide.
- Page 8 Enjoy your rejuvenated Monitor. Call us to order more HMI replacement parts. M20A03-080QTMATE/080QT0744...
- Page 9 Keep your PANELMATE HMI’s up and running! ML080MATE -8" LCD Upgrade for ML121LLMATE -12.1" LCD (Panelmate/Cutler) with 9" CRT. Just Upgrade for (Panelmate/Cutler) take a picture of your video connector with 14" CRT. Just take a picture of your video connector MF1775T- Touchscreen and overlay MPC21P -LCD Panel kit for the PanelMate 1775K...
- Page 10 For Technical Support, Call 1-877-493-6105 Support@Monitech.com M20A03-080QTMATE/080QT0744...
- Page 11 20 Howard Place Kitchener, Ontario N2K 4Z4 CANADA 519.725.2222 www.monitech.com M20A03-080QTMATE/080QT0744...
- Page 12 M20A03-080QTMATE/080QT0744...
