- Page 1 KNIPEX Quality – Made in Germany Operating instructions 12 42 195 Automatic Insulation Stripper for stripping fine-stranded wire to solid round cables...
-
Page 2: Table Of Contents
CONTENTS General Notes on operating instructions Symbols used Copyright Guarantee and warranty Safety Intended use Design and function Design Function Operation Cutting cables Stripping cables (with single, multi and fine-stranded conductors) 7 Maintenance Changing the feed stop Changing the blade unit Technical data Disposal Status: 04.04.23... -
Page 3: General
These operating instructions and all documentation supplied with this tool are protected by copyright and remain the property of KNIPEX. The reprinting of these instructions, even in extract form, is only permitted with the written consent of KNIPEX Werk C. Gustav Putsch KG. Status: 04.04.23... -
Page 4: Guarantee And Warranty
• Repairs or conversions are carried out by unauthorized persons. • Original accessories or spare parts from KNIPEX are not used. • Defective components are not repaired immediately to minimise the extent of the damage and so as not to impair the safety of the tool (obligation to repair). -
Page 5: Design And Function
DESiGN aND fuNCTiON Design and function 3.1 Design 12 42 195 0,03 – 10,0 < 10 mm < 6 mm Design of the stripping tool Holder for cables / conductors Blades for wire stripping Adjustable feed stop (4.0 to 18.0 mm) Wire cutter for fine-stranded copper and aluminium conductors (max. -
Page 6: Operation
OpEraTiON Operation 4.1 Cutting cables < 10,0 mm < 6,0 mm Trim cable 1. Insert the end of the cable to be cut between the two blades of the wire cutter. 2. Firmly press the two handles together. Status: 04.04.23... -
Page 7: Stripping Cables (With Single, Multi And Fine-Stranded Conductors)
OpEraTiON 4.2 Stripping cables (with single, multi and fine-stranded conductors) » Set the length stop to the required size (4 to 18 mm).* » Insert the end of the cable into the holder. » Firmly press the two handles together. 0,03 - 10 mm Stripping single conductors »... -
Page 8: Maintenance
MaiNTENaNCE Maintenance 5.1 Changing the feed stop Replacing the feed stop 1. Press the feed stop together lightly and pull it off the guide. 2. Place the new length stop onto the guide and gently press it together until it clicks into place. 3. -
Page 9: Changing The Blade Unit
MaiNTENaNCE 5.2 Changing the blade unit 5.2.1 Removing the blade unit 1. With the pliers open, insert a small screwdriver into the hole above the blade unit and connecting bar. 2. Squeeze the handles and use the screwdriver to pry the blade unit off the connecting bar. - Page 10 MaiNTENaNCE 3. Grip the blade unit with your thumbs at the feed stop and push it upwards. Warning! Warning: Sharp blades! Handling sharp blades is dangerous. For this reason, make sure to handle your tools with care when working. 4. Tip the blade unit to the side and pull it out in a downwards move- ment.
- Page 11 MaiNTENaNCE 5.2.2 Inserting a new blade unit 1. Lightly squeeze the new blade unit and insert it into the tool at an angle. 2. Push the blade unit joint downwards. 3. Let the handles of the pliers spring open. The connecting bar slips onto the joint of the blade unit and engages with an audible click.
-
Page 12: Technical Data
TEChNiCal DaTa Technical data 6.1 Technical data Technical data Unit Item number Pliers – 12 42 195 Item number Spare blades block – 12 49 21 Item number Spare length stop – 12 49 23 Item number Torsion spring –... - Page 13 KNIPEX-Werk C. Gustav Putsch KG 42337 Wuppertal Tel.: +49 202 – 47 94-0 Fax: +49 202 – 47 74 94 info@knipex.com www.knipex.com...
