Kaizen KZ-PB10KACW User Manual

Product Overview
A B
C
D
Charging
Connect the supplied USB-C cable to the USB-C port on the device and the other end to a power source. The battery
LED indicators will flash white whilst charging. Please fully charge the powerbank before use. Once fully charged, the
battery LED indicators will light up white.
Connect a USB cable (not included) to the USB port and the other end to your device. The powerbank will start
charging the connected device.
When fast charging or discharging the indicator will light up Blue (The fourth light).
LED indicator status
LED
Battery
100-75% 75-50%
capacity
Wireless Charging: Place your smart phone facing up on the wireless charging pad and presss the Battery
indicator button. One of the battery LED indicators will light up red (the end light) once the phone is correctly
aligned and will start to charge.
Note: your smart phone must support wireless charging.
If your smart phone does not charge, this indicates that the smart phone does not support wireless charging
and/or other objects are obstructing the wireless charging pad.
Troubleshooting
Cannot charge device
Wireless charging not
working
No LED light when
charging device
E
50-25% 25-0%
• Make sure the USB-C or USB-A cable is plugged into the output port.
• Try another USB-C or USB-A charging cable.
• Check that your smart phone supports wireless charging.
• If you have a smart phone case, you must remove when charging.
• Ensure your smart phone is facing up and aligned to the centre of the wireless charging
pad, and remove any metal or other objects between the smart phone and the wireless
charging pad.
• Connect the power bank to your power source to ensure the power bank has sufficient
battery.
10,000 mAh WIRELESS POWER BANK
A. Battery LED indicators and charging indicators
B. Battery indicator button - press this button to check the
battery level or start for wireless charge
C. USB-C port (Input & Output)
D. USB Port
E. Wireless Charging Pad
User Guide
KZ-PB10KACW
