User Manual for LCO-2000 Console
www.levitronix.com
®
PuraLev
Console
LCO-2000
®
®
PuraLev
2000SU and PuraLev
2000MU
USER MANUAL
This manual contains information necessary for the safe and proper use of the PuraLev
®
LCO-2000 Console.
Included are specifications for the standard configurations and instructions regarding its use, installation,
operation, adjustment, inspection and maintenance. For detailed description of the menu structure and the
configuration possibilities with the touch screen of the LCO-i100 console user interface the console software
manual PL-4067-00 can be consulted. For all in this manual revision described configurations and features
the LCO-i100 console software V1.04 R13 or higher is needed. For special configurations of the system
refer to accompanying information. Please familiarize yourself with the contents of the manual to ensure the
safe and effective use of this product. After reading this manual, please store the manual where the
personnel responsible for operating the pump system can readily refer to it at any time.
First Release: 15-Jun-17
PL-4070-00, Rev01, DCO# 20-092
Last Update: 02-Apr-20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PuraLev LCO-2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Levitronix PuraLev LCO-2000

  • Page 1 User Manual for LCO-2000 Console www.levitronix.com ® PuraLev Console LCO-2000 ® ® PuraLev 2000SU and PuraLev 2000MU USER MANUAL This manual contains information necessary for the safe and proper use of the PuraLev ® LCO-2000 Console. Included are specifications for the standard configurations and instructions regarding its use, installation, operation, adjustment, inspection and maintenance.
  • Page 2: Table Of Contents

    User Manual for LCO-2000 Console www.levitronix.com Table of Contents SAFETY PRECAUTIONS ................................3 SPECIFICATIONS ..................................4 Specification of Console Components ........................... 4 System Overview and General Specification ......................... 6 2.2.1 Basic Stand-Alone System Configuration with LCO-i100 ..........................6 2.2.2 Extended System Configuration with LCO-i100 ..............................6 General Environmental Conditions ............................
  • Page 3: Safety Precautions

    Concerning safety precautions for motor, pump and sensors refer to the corresponding manuals. CAUTION ® Do not under any circumstances open the console enclosure. Levitronix does not assume responsibility for any damage, which occurs under such circumstances.
  • Page 4: Specifications

    User Manual for LCO-2000 Console www.levitronix.com 2 Specifications 2.1 Specification of Console Components Figure 1: LCO-2000 console with compatible motors and pump heads Figure 2: Sensors compatible with LCO-i100 user interface console (in context with LCO-2000 console) Figure 3: Accessories (cables and others)
  • Page 5 Mounting Type / Material Mounting with 4x 25mm screws, anodized aluminum Table 2: Specification of standard pump motors and single-use pump heads compatible with LCO-2000 console Note 1: Gamma irradiated options available. Note 2: See Levitronix ® technical brochures of PuraLev ®...
  • Page 6: System Overview And General Specification

    User Manual for LCO-2000 Console www.levitronix.com 2.2 System Overview and General Specification 2.2.1 Basic Stand-Alone System Configuration with LCO-i100 With the stand-alone pump system configuration, as illustrated in Figure 4, the speed of the pump can be manually set, ®...
  • Page 7: General Environmental Conditions

    User Manual for LCO-2000 Console www.levitronix.com 2.3 General Environmental Conditions Usage Indoor (Laboratory, Industrial environments) Altitude Up to 2000 m Operating ambient temperature 10 to 40 °C Storage ambient temperature (Extremes for Transportation) -20 to 70 °C 15 – 95% (non-condensing) Operating humidity range (relative humidity) 15 –...
  • Page 8 User Manual for LCO-2000 Console www.levitronix.com 4 Mounting Holes for screws inside the box. Cable Bushing: Tightening torque: 3 Nm Clamping range: 8 – 13 mm. Figure 7: Basic dimensions (in mm) of AC cable AMC-3.3 (Dimensions without tolerances are for reference only.) Figure 8: Basic dimensions (in mm) of console LCO-i100 (Dimensions without tolerances are for reference only.)
  • Page 9: Engineering Information

    User Manual for LCO-2000 Console www.levitronix.com 3 Engineering Information 3.1 IP Rating The console LCO-2000 is designed and tested to meet IP54. A temperature controlled fan inside the console, which is protected by a watertight filter and a sealed cover as illustrated in Figure 9 provides cooling of the electronics inside the console.
  • Page 10: Installation

    User Manual for LCO-2000 Console www.levitronix.com 4 Installation 4.1 Mechanical Installation of LCO-2000 4.1.1 Mounting Positions Figure 11 : Mounting positions of console LCO-2000 For wall-mounting of the console the 4 pre-assembled rubber feet on the back side have to be removed. The underlying 6 M8 threads can be used for the wall-mounting according to the specifications in Figure 6.
  • Page 11: Electrical Installation Of Lco-2000

    Motor Sensor PuraLev 2000 Sensor connector for LPM-2000 motors. M23 metallic connector. ® RS232 to internal controller. For operation with Levitronix Service Software or remote control with RS232 For operation without LCO-i100. other devices. PLC of internal pump controller. 4x digital outputs, 4x digital inputs, 1 analog output (5V), 1x analog input For operation without LCO-i100.
  • Page 12: General Installation Instructions

    User Manual for LCO-2000 Console www.levitronix.com 4.3.2 General Installation Instructions WARNING Hazardous voltage may be present. Always switch off the LCO-2000.1 console before performing any changes to the connections, the positioning and before doing other maintenance activities. Hazardous voltage is present until 60 seconds after switching off. Do not handle the console during this time.
  • Page 13 User Manual for LCO-2000 Console www.levitronix.com Torque Specifications: = 200 – 240 Vrms ± 10% 1-Phase Cable Gland: 3 Nm AC Mains Housing Screws: 0.6 Nm 1-Phase Cable to Console To Mains Specification for AC Cable To Mains 1-Phase: Cable OD = 8 - 13 mm Wires US: AWG14 Wires IEC: 2.5 mm...
  • Page 14: Installation Of Motor Connectors To Console

    Figure 16: Wrong and correct Hummel connector type assembly of LPM-2000 motors 4.3.4 RS232 Interface ® For usage of Levitronix Service Software with a PC or for remote control with other devices than the LCO-i100 the RS232 can be used. A relevant protocol for remote control is available on request (see specifications for standard controller firmware E4.38).
  • Page 15: Plc Interface

    User Manual for LCO-2000 Console www.levitronix.com 4.3.5 PLC Interface Wire Standard Pin# Description Typical Levels Note Color Designation red-blue Digital Out1 Galvanic isolation with relay. Relay closed  active, system on Relay: 1 A / 30VDC, 0.3A / 125VAC Status Relay open ...
  • Page 16: Electrical Installation Of Lco-I100

    Figure 17 shows the various interfaces of the LCO-i100 console. The corresponding designations are described in Table 11. For detailed descriptions and installation instructions consult the LCO-i100 manual ( document # PL-4061-00) available at Levitronix ® Figure 17: Interfaces of console LPC-i100 Note 1: All connectors come delivered with a protective cap for a min.
  • Page 17: Operation

    User Manual for LCO-2000 Console www.levitronix.com 5 Operation The console LCO-i100 contains a self-explaining touch screen user interface with various menus to operate, configure and troubleshoot the system. In this section only the basic functions for a safe usage are explained. For more details consult the LCO Console Software Manual PL-4067-00.
  • Page 18: Auto-Resume Feature Lco-I100

    LCO-2000. A new software/firmware package will be provided © by Levitronix as a single file with the file ending *.levi. Follow the procedure below for an update: 1. Put the *.levi file of a FAT32 formatted USB memory and insert it into the front USB connection of the LCO-i100 console.
  • Page 19: Maintenance

    If problems or failures can’t be solved with the help of the notification on the console screen, it is recommended to capture a data log during operation, as described in LCO Console Software Manual PL-4067-00, until the ® failure appears and then send the data log file to the Levitronix Technical Service Department or the appropriate key account manager.
  • Page 20: Appendix

    Industrial, scientific, med. equipment - Radio-frequency disturb. characteristics - Limits and methods of measurm. 9.1.2 IECEE CB Safety Certification ® The Levitronix LCO-2000 Console are 3 party tested and certified by Electrosuisse following the IECEE CB Scheme according to the following safety standards: Safety requirements for electrical equipment for measurement, control and laboratory use.
  • Page 21: Symbols And Signal Words

    User Manual for LCO-2000 Console www.levitronix.com 9.2 Symbols and Signal Words Symbol / Description Type Source Signal Word Indication of an imminently hazardous situation that, if not DANGER Signal word SEMI S1-0701 avoided, will result in death or severe injury. Limited to the...
