RCN SCC 250 PPG SB Instructions For Use And Information Manual

Instructions for use and information
on the product for medical devices according to Regulation 2017/745
RCN Medizin- und Rehatechnik GmbH, Hauptstraße 4, D-55471 Sargenroth
Tel +49 (0) 67 61 / 91 97 0, Fax +49 (0) 67 61 / 91 97 70, Email: info@rcn-medizin.de
Shower chairs/multifunctional toilets
SCC 250 PPG SB
Content
1 Introduction ......................................................... 1
2 Intended use ....................................................... 1
3 General safety rules............................................ 1
4 Use and functions .............................................. 1
5 Accessories ........................................................ 3
6 Technical data .................................................... 3
7 Identification mark ............................................... 3
8 Cleaning and disinfection ................................... 4
9 Maintenance and inspection ............................... 4
10 Storage, reuse, treatment of waste .................. 4
11 Warranty / Liability ............................................ 4
1 Introduction
These instructions for use contain important
information about the use of the product. Read the
instructions carefully and follow the safety
instructions in particular.
2 Intended use
This model is intended as an aid for showering,
grooming and personal hygiene. In addition, the
mobile chair with footrest can be used as a transport
chair in the shower room. The backrest and
armrests ensure a stable sitting position.
Indication: The product provides support in case of
reduced mobility or
Contraindication: Inability to sit.
Product lifetime: The expected lifetime is 10 years.
Depending on the wear and tear of certain
components (e.g. wheels and cushions), it may be
necessary to replace them earlier. The use of spare
parts will increase the service life.
EN
loss of balance.
IFU_EN_SCC250PPGSB_V01 en-GB.docx
3 General safety rules
Only use the product on flat surfaces indoors. Avoid
moving around independently while fiddling, as your
feet could get caught under the frame.
Do not shift your weight by tilting your upper body to
the side, front or back, e.g. by picking up objects.
This can cause the model to tip over.
After each use, remove any traces of soap from the
chair to avoid accidents due to the risk of slipping.
The model can be permanently subjected to a
temperature range of 0 °C to 60 °C. Due to the
properties of the plastic, a load outside this
temperature range may cause damage. Also, do not
expose the product to point loads of heat, such as
radiators. Before each use, check the product for
damage. If damaged, do not use the product again
until it is repaired.
All serious incidents related to this product should
be reported to us (manufacturer) and the relevant
authorities.
4 Use and functions
- 75 mm wheels
The model is equipped with four 75 mm double
wheels with free rotation. The chair may only be
used with the help of an attendant. Do not exceed
the walking pace when using the chair.
All wheels are equipped with a parking brake. When
transferring a person from the shower or toilet, all
parking brakes must be locked.
- Extendable footrest FT
The footrest is used for placing the feet. The footrest
is slidably attached to the lower frame posts, making
it easy to move the footrest into position by sliding it
forward or backward. The support bars underneath
the footrest with non-slip feet keep the footrest
stable and prevent the chair from tipping forward. If
the chair is retrofitted with larger castors, the
support bars must also be extended.
1
