Plastica X-STREAM SINGLE Instruction Manual page 2

Installing the X-Stream Counter Current System
1. If you have an X-stream 2. Fix the X-stream unit
counter current unit place it in place using the fixings
in the pre-cut whole. It may supplied with the unit.
be necessary to even out
the fitment by packing the
bottom of the unit with a thin
piece of wood or similar,
from the outside of the pool,
remove the grab bar and facia
plate from the unit and keep
all parts safe.
4. X-Stream Duo model 5. X-Stream Duo model
only; If you have an X-Stream only; Apply one of the self-
Duo pool you will need to fit adhesive gaskets carefully
the extra 63mm suction point to the suction point, then
using the screws Provided partially insert two screws
with the fitting, again keep with the cross hairs pointing
all the other parts safe until North, South, East and West
required. as the image shows below.
2
3. Remove the nozzles from 7. Pay particular attention to
the counter current unit and pressing the foam underlay
keep all the parts in order firmly into the corners and
somewhere safe. Carefully under the liner-lock of the
stick one of the gaskets to pool. Avoid getting adhesive
the unit, ensuring the holes on any fittings such as the
for the machined screws inlets or skimmer.
match up. Then partially
insert a screw in each corner. Trim around the perimeter of
the pool by running a sharp
pair of scissors directly under
the liner lock. Cut the foam
away neatly around any pool
fittings.
6. Image shows gaskets and 9. Again, before you start
screws in place on skimmer cutting in fittings for the
X-Stream unit, inlet and X-stream unit the water level
low-level suction. should be approximately
50mm below the screw heads
which should be visible from
behind the liner. Carefully
expose the screw heads and
four threaded lugs using the
same method as when cutting
in the inlets. Start with a small
cross incision in the centre of
the screw keeping it as small
as possible but just enough,
to stretch the liner over the
screw/threaded lug.
8. Before cutting in the
fittings on the liner Plumb up
any filtration/counter current
pipework.
Installing the X-Stream Counter Current System
10. Carefully attach the
gasket to the faceplate
ensuring all the holes line up.
Then you can undo one of the
corner screws and thread it
back through the hole. This
will help you locate the other
three corners. Once you have
all 4 screws in place tighten
them by hand with a hand-
held screwdriver.
– Liner Cutting Instructions
11. Now you have the face
plate in position, use a sharp
pointy object like a screw
to make a small hole for
each machined screw to go
through, each hole on the
face plate.
