Attachment Label
T1
T2
T4
T5
T6*
T7
T8
B1
B2
NOTE
If UART Switch connected to above two pins by jumper，the debug UART will connect to EVB;
If UART Switch connected to below two pins by jumper，the UART3 will connect to EVB.
www.simcom.com
Figure 2: TE Bottom View
Description
Module
Main Antenna Connector
Micro USB Connector
Micro USB Connector
UART Switch
SIM Card Holder
Test Point
Connector (Connect to SIMCOM-EVB)
Connector (Connect to SIMCOM-EVB)
