Summary of Contents for XERO2 FLEA
- Page 1 Product Information...
- Page 2 READ THIS BEFORE USING YOUR XERO2 PRODUCT. This guide contains information related to the safe and lawful use of this product. Failure to understand and comply with the information contained within this guide may result in fines, serious injury, or death.
-
Page 3: Table Of Contents
1.2 Stem Alignment 1.3 Handlebar Installation 1.4 Charging 2 PRODUCT OPERATION 2.1 Product Control Overview 2.2 Powering On & Off 2.3 Throttle 2.4 Power Boost 2.5 Before Every Ride 3 CARE & MAINTENANCE 4 PRODUCT WARRANTY 5 PRODUCT SPECIFICATIONS www.xero2.com... -
Page 4: Getting Started
1.1 Unboxing WARNING - OVERSIZED/HEAVY CARTON Xero2 recommends at least two people for lifting the carton and unboxing the product. Xero2 products come partially assembled in box. We recommend seeking professional help to setup your eBike as it may require additional professional tuning. -
Page 5: Stem Alignment
1.2 Stem Alignment \\ ROTATE STEM 180° UNTIL THE FOUR HANDLE BAR MOUNTING PLATE BOLTS FACE FORWARD AND ARE ALIGNED PARALLEL WITH THE FRONT TIRE. TIGHTEN WITH INCLUDED WRENCH UNTIL SNUG. Do not over-tighten. If you are uncertain about assembly procedures, contact a professional to have your eBike professionally assembled. -
Page 6: Handlebar Installation
1.3 Handlebar Installation REMOVE THE FOUR BOLTS LOCATED AT THE FRONT OF THE HANDLEBAR MOUNTING PLATE USING THE INCLUDED ALLEN KEY. POSITION HANDLEBAR ASSEMBLY ON THE HANDLEBAR MOUNTING PLATE AND ALIGN CLAMP SCREW HOLES WITH THE MOUNTING PLATE SCREW HOLES. REPLACE THE REMOVED BOLTS AND TIGHTEN HANDLEBAR CLAMPS TO THE HANDLEBAR MOUNTING PLATE. -
Page 7: Charging
- Avoid allowing battery to fully discharge to empty. Charging - Flashing Light Fully Charged - Solid Light Fully charge your Xero2 eBike for at least 4 hours prior to first use. Use only the XERO2 charger included with your eBike. -
Page 8: Product Operation
2 Product Operation \\ 2.1 Product Control Overview 2.2 Powering On/Off Power Switch Rear Hand Brake Throttle POWERING ON AND OFF - PUSH AND HOLD THE POWER BUTTON FOR 2 SECONDS AND WAIT FOR POWER INDICATOR LIGHT TO TURN ON/OFF. PUSH &... -
Page 9: Throttle
FORWARD, RELEASE THE THROTTLE. POWER FORWARD The Flea eBalance bike’s power limiter is active by default at start up. To increase both torque and acceleration, activate the power boost button located under the seat. POWER BOOST - TO ENGAGE POWER... -
Page 10: Before Every Ride
Make sure tires are inflated properly. Over-inflation and/or under-inflation of tires can cause damage or dangerous riding circumstances. Tires have a maximum rated psi rating located on side wall of tires, do not inflate past this level. Xero2 recommends a maximum 40psi for both front and rear. SPOKES Spokes should be tight and straight. -
Page 11: Care & Maintenance
3 Care & Maintenance \\ BATTERY CARE Observing the following guidelines can help extend the life of your XERO2 battery. - When the removable battery is fully charged, disconnect from power supply. - Avoid charging for more than 8 hours. -
Page 12: Product Warranty
Defects or damage caused from misuse will not be covered under warranty. Certain components of Xero2 bikes are considered wear items and will not be covered under warranty. Any damage to Xero2 products by the consumer which are caused by accidents will not be covered under warranty. Customer/ Original purchaser is responsible for shipping charges relating to warranty work. -
Page 13: Product Specifications
5 Product Specifications \\ GENERAL INFORMATION POWER Classification eBalance Bike Battery 18v 5ah DC/DC Frame Steel 48v to 12v (120 watt) Converter Weight 28 Lbs. Charger 3.0a charger Weight Limit 80 Lbs. Range 60 Minutes Maximum Seat Height 18.5 in. DRIVE Seat Type Single Passenger... - Page 14 [ Intentionally Left Blank ]...
- Page 15 [ Intentionally Left Blank ]...
- Page 16 www.xero2.com...
