- Page 1 Product Information...
- Page 2 READ THIS BEFORE USING YOUR XERO2 PRODUCT. This guide contains information related to the safe and lawful use of this product. Failure to understand and comply with the information contained within this guide may result in fines, serious injury, or death.
-
Page 3: Table Of Contents
1 GETTING STARTED 1.1 Unboxing 1.2 Pedal Installation 1.3 Handlebar Installation 1.4 Charging 2 PRODUCT OPERATION 2.1 Product Control Overview 2.2 Powering On & Off 2.3 Throttle 2.4 Before Every Ride 3 CARE & MAINTENANCE 4 PRODUCT WARRANTY 5 PRODUCT SPECIFICATIONS www.xero2.com... -
Page 4: Getting Started
1.1 Unboxing WARNING - OVERSIZED/HEAVY CARTON Xero2 recommends at least two people for lifting the carton and unboxing the product. Xero2 products come partially assembled in box. We recommend seeking professional help to setup your eBike as it may require additional professional tuning. -
Page 5: Pedal Installation
1.2 Pedal Installation \\ INSERT PEDAL INTO THE CRANK ARM. TIGHTEN WITH INCLUDED WRENCH UNTIL SNUG. Do not over-tighten. Pedals are directional (left and right) and must be installed on the corresponding crank arm. If you are uncertain about assembly procedures, contact a professional to have your eBike professionally assembled. -
Page 6: Handlebar Installation
1.3 Handlebar Installation If you are uncertain about assembly procedures, contact a professional to have your eBike professionally assembled. REMOVE THE TWO BOLTS LOCATED ON THE UNDERSIDE OF THE HANDLEBAR MOUNTING PLATE USING THE INCLUDED ALLEN KEY. POSITION HANDLEBAR ASSEMBLY ON THE HANDLEBAR MOUNTING PLATE AND ALIGN CLAMP SCREW HOLES WITH THE MOUNTING PLATE SCREW HOLES. -
Page 7: Charging
LED COLOR CODES - Avoid allowing battery to fully discharge to empty. RED - Charging GREEN - Fully Charged Fully charge your Xero2 eBike for at least 4 hours prior to first use. Use only the XERO2 charger included with your eBike. -
Page 8: Product Operation
2 Product Operation \\ 2.1 Product Control Overview BATTERY LEVEL CODES F - Fully Charged E - Empty/Fully Discharged Controller/Power Switch Front Hand Brake Rear Hand Brake Battery Level Display Headlight Switch... -
Page 9: Powering On & Off
(LEFT) WILL POWER OFF YOUR EBIKE. There is a 0.5 second start-up throttle delay when turning on the eBike. Xero2 eBikes use a half-twist throttle. Be familiar with the throttle operation before riding. THROTTLE OPERATION - TO POWER THE EBIKE... -
Page 10: Before Every Ride
Make sure tires are inflated properly. Over-inflation and/or under-inflation of tires can cause damage or dangerous riding circumstances. Tires have a maximum rated psi rating located on side wall of tires, do not inflate past this level. Xero2 recommends 25-30psi for both front and rear. SPOKES Spokes should be tight and straight. -
Page 11: Care & Maintenance
3 Care & Maintenance \\ BATTERY CARE Observing the following guidelines can help extend the life of your XERO2 battery. - When eBike is fully charged, disconnect from power supply. - Avoid charging for more than 8 hours. - Avoid allowing battery to fully discharge. -
Page 12: Product Warranty
Defects or damage caused from misuse will not be covered under warranty. Certain components of Xero2 bikes are considered wear items and will not be covered under warranty. Any damage to Xero2 products by the consumer which are caused by accidents will not be covered under warranty. Customer/ Original purchaser is responsible for shipping charges relating to warranty work. - Page 13 [ Intentionally Left Blank ]...
- Page 14 [ Intentionally Left Blank ]...
-
Page 15: Product Specifications
5 Product Specifications \\ GENERAL INFORMATION POWER 48v 19.2ah 921.6wh Classification Class 2 Battery (Samsung cells) Frame Steel DC/DC 48v to 12v (120 watt) Converter Weight 70 Lbs. Charger 100v-240v 2.0a charger Weight Limit 250 Lbs. Range 30 miles Seat Height 28.5 in. - Page 16 www.xero2.com...
