- Page 1 ANT-48100 QUICK START GUIDE 1 Channel Transcoder (4 Channel Decoder) Antrica Quick Start Guide v2.0 ANT-48100 Series Page 1...
- Page 2 6.0 Other Information Overview The ANT-48100 TRANSCODER is a highly flexible IP to IP transcoder. Featuring up to 4 channels of decoding on one Ethernet port (NIC) and 1 channel of re encoding (Transcoding) on a second Ethernet Port (NIC). This transcoder is intended for IP to IP transcoding without offering any local video inputs or outputs.
- Page 3 -12 Volt Power converter with UK/EU/USA and China adaptors 2. Setting up the ANT-48100 Connect the both of the Ethernet ports of the ANT-48100 to a laptop or PC via an Ethernet switch using standard ethernet cables. Connect the 12 volt power input and switch on.
- Page 4 4.2 Network This section defines the network settings of the IP Ethernet input port. NOTE! The ANT-48100 has two ethernet ports (NICs) which are independent. This setting is for the IP input (decode) Antrica Quick Start Guide v2.0 ANT-48100 Series...
-
Page 5: Video Source
Input: 1-4: These are the URLs for the 4 decoded inputs. Generally, you would use 1 input in 1x1 mode or 2, 3 or 4 inputs for 2x2 mode. Audio Channel: Future use / functionality to be advised Antrica Quick Start Guide v2.0 ANT-48100 Series Page 5... - Page 6 Update: This allows firmware for the decoder section to be upgraded Version: The firmware currently installed for the Decoder part of the Transcoder. Timing Reboot: Allows the Decoder section to be rebooted automatically every N Hours ( 0-200 Hours) Antrica Quick Start Guide v2.0 ANT-48100 Series Page 6...
- Page 7 5.0 Setup of the ANT-48100 in IP OUTPUT (Encoder) (192.168.1.168) 5.1 Status Status shows information about the Encoder section of the ANT-48100 Transcoder and is broken down into 4 sections: Access Address: The URL of the encoded stream depending what stream method is selected HTTP RTSP RTP etc .
- Page 8 Video Parameters: shows the resolution and frame rate of the signal input being supplied by the decoder section, and the encoding frame rate as set in the Output 1 section Hardware Status: Future use / functionality to be advised Antrica Quick Start Guide v2.0 ANT-48100 Series Page 8...
- Page 9 This section defines the Encoder parameters, type off Codec and all other encoder settings. As this is a quick start guide only the basics will be mentioned. Output 1: This is Encoders main stream. The sub stream is Output 2 Antrica Quick Start Guide v2.0 ANT-48100 Series Page 9...
- Page 10 HTTP: Select Enable if you wish to use http streaming and edit the stream identifier RTSP: Select Enable to use RTSP mode and edit the stream RTSP Authentication: Enable user name password RTSP authentication RTSP Mode: Video + Audio, video or Audio only Antrica Quick Start Guide v2.0 ANT-48100 Series Page 10...
- Page 11 RTMP Mode: Define video + Audio, Video or Audio only SRT: Enable SRT here and define if listener or caller 5.3 Extended 5.3.1 Audio Setting The audio settings for the audio with the streamed video Antrica Quick Start Guide v2.0 ANT-48100 Series Page 11...
- Page 12 This is to enable RTMP and HLS streaming. The RTMP-HLS stream needs to be set to open to allow the preview video to be section, as mention in Preview in the Status setting (Section 5.1) Antrica Quick Start Guide v2.0 ANT-48100 Series Page 12...
- Page 13 5.3.6 Smart Encoder Future use / functionality to be advised 5.4 System System Settings Tab: This allows the Encoder section of the transcoder to be Factory Reset or rebooted Antrica Quick Start Guide v2.0 ANT-48100 Series Page 13...
- Page 14 Change Password: Allows for the default admin password or previously used password to be changed. Version: The firmware currently installed for the Encoder part of the Transcoder. Update: This allows firmware for the decoder section to be upgraded Antrica Quick Start Guide v2.0 ANT-48100 Series Page 14...
-
Page 15: Other Information
6.0 Other Information Please visit our website www.antrica.com and browse to the product page (e.g ANT- 48100 ) where you can find a DOWNLOADS SECTION : - application notes - Full User manuals - FAQs - Firmware - Other useful information - More help Open up a Technical Support Ticket from the support page.
