- Page 1 ANT-48100 User Manual 1 Channel Transcoder (4 Channel Decoder) Antrica Quick Start Guide ANT-48100 Series V12021 Page 1...
-
Page 2: Table Of Contents
Contents Overview 1.0 Whats in the box 2.0 Setting up the ANT-48100 3.0 Configuring the ANT-48100 4.0 Network 5.0 Operation Mode 6.0 Encoder 7.0 Decoder 8.0 Transcoder 9.0 Mixer Mode 10.0 Display 11.0 Extensions 12.0 System 13.0 Other Information Antrica Quick Start Guide... -
Page 3: Overview
Overview The ANT-48100 TRANSCODER is a highly flexible IP to IP transcoder. Featuring up to 4 channels of decoding on one Ethernet port (NIC) and 1 channel of re-encoding (Transcoding) on a second Ethernet Port (NIC). This transcoder is intended for IP to IP transcoding without offering any local video inputs or outputs. -
Page 4: Setting Up The Ant-48100
Connect the 12 volt power input and switch on. The ANT-48100 will take approximately 1 minute to boot up. You will see there are 3 LEDS on the front panel …Power, Not Used and LAN. On power up the RED LED will illuminate and the Green LAN LED will illuminate if connected via ethernet to a switch or laptop PC. -
Page 5: Network
4.2 Network This section defines the network settings of the IP Ethernet input port. NOTE! The ANT-48100 has two ethernet ports (NICs) which are independent . This setting is for the Transcoder IP input (decode) Antrica Quick Start Guide... - Page 6 1 input in 1x1 mode or 2,3 or 4 inputs for 2x2 mode . Audio Channel: This defines which URL Input you will be using as the source of the audio . Enter XXXXXXXXXX in this section Antrica Quick Start Guide ANT-48100 Series V12021 Page 6...
- Page 7 In this section you are able to XXXXXXX Intranet Search or Manual input: Allows you to XXXXXXXX Play: This will enable XXXXXXX 4.3.3 SRT Settings This section allows Secure Reliable Transport settings to be input if XXXXXXXX Antrica Quick Start Guide ANT-48100 Series V12021 Page 7...
-
Page 8: System
Change Password: Allows for the default admin password or previously used password to be changed. Update: This allows firmware for the decoder section to be upgraded Version: The firmware currently installed for the Decoder part of the Transcoder. Antrica Quick Start Guide ANT-48100 Series V12021 Page 8... - Page 9 5.0 Setup of the ANT-48100 in IP OUTPUT (Encoder) mode (192.168.1.168) 5.1 Status Status shows information about the Encoder section of the ANT-48100 Transcoder and is broken down into 4 sections: Access Address: The URL of the encoded stream depending what stream method is selected HTTP RTSP RTP etc .
- Page 10 Video Parameters: Defines the resolution and frame rate of the encoder input being supplied by the decoder section. Hardware Status: A visual indication of XXXXXXX Preview: Allows a preview of the encoded video stream if using Chrome as a browser. XXXXXXX Antrica Quick Start Guide ANT-48100 Series V12021 Page 10...
- Page 11 Bitrate Control: CBR or VBR modes Key Interval: This is the GOP for the encoder ratio of I to P frames. Encoded Size: Streams the Decoded image or scales this image based on these settings Antrica Quick Start Guide ANT-48100 Series V12021 Page 11...
- Page 12 PMT ID: XXXXXXXX Transport ID: XXXXXXX Stream ID : XXXXXXX Program ID: XXXXXXXX SDT Name: XXXXXXXXXXXXXX HTTP: Select Enable if you wish to use http streaming and edit the stream identifier Antrica Quick Start Guide ANT-48100 Series V12021 Page 12...
- Page 13 RTMP URL: If using URL mode set the URL here. If using IP mode then other boxes will appear regarding server details for RTMP IP streaming SRT: Enable SRT here and define if listener or caller Antrica Quick Start Guide ANT-48100 Series V12021 Page 13...
- Page 14 Text can be written and positioned like the logo file using X and Y co-ordinates and font size/ colour and alpha can be selected. Note! The Logo file must be encoded as a XXXXXXXbit bitmap 5.42 Color Setting Antrica Quick Start Guide ANT-48100 Series V12021 Page 14...
- Page 15 Color setting allows adjustment of the OSD parameters. 5.43 Image Setting 5.44 RTMP-HLS Setting In this section if using RTMP or HLS parameters are input here. 5.45 Smart Encoder Antrica Quick Start Guide ANT-48100 Series V12021 Page 15...
-
Page 16: Other Information
Smart encoder allows for XXXXXXXXXX 13.0 Other Information Please visit our website www.antrica.com and browse to the product page (e.g ANT-48100 ) where you can find a DOWNLOADS SECTION : - application notes - Full User manuals - FAQs - Firmware - Other useful information - More help Open up a Technical Support Ticket from the support page.
