Assembly Instructions
Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts that may have
come loose inside the carton during shipment. Please read all instructions carefully before starting the assembly process.
CAUTION: Some items and/or the components are cumbersome and heavy.Therefore, the assistance of one or more people
is recommended in order to prevent personal injury and insure that the item and/or its components are not damaged during
the assembly process. Perform all assembly steps on a flat, soft, non-abrasive surface. Do not overtighten the screws or bolts.
No.
Diagram, Description, & Size (mm)
Side Frame
465 x 392 x 34
Top Assembly
406 x 406 x 54
Bottom Shelf Assembly
378 x 324 x 34
Note: A bottle of Espresso Touch-up Oil (G) was provided for
your convenience. Do NOT discard. Use when necessary to
touch-up and repair minor nicks, scratches and/or abrasions.
1. Place the top assembly (B) upside down
and loosely install both side frames (A)
using the F-screws (D) as indicated in
Figure I. DO NOT completely tighten
the F-screws at this time.
12:16 AM
Page 1
Nature's Retreat
Parts & Hardware List
Qty
! KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE !
™
Side Table
No.
Diagram, Description, & Size (mm)
HW-ST-01-042
F-Screw 7x60
HW-ST-18-001
Allen key 4x98
HW-MM-06-075
Adjustable Leveling Glide Ø22x27
Espresso Touch-up Oil
Figure I
Model # 12260-002/012
