Assembly Instructions
Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts that may have come
loose inside the carton during shipment. Please read all instructions carefully before starting the assembly process.
CAUTION: Some items and/or the components are cumbersome and heavy. Therefore, the assistance of one or more people
is recommended in order to prevent personal injury and insure that the item and/or its components are not damaged during the
assembly process. Perform all assembly steps on a flat, soft, non-abrasive surface to avoid scratching the finish. Do not over-
tighten the screws or bolts.
No.
A1
Table Top (with glass packed inside)
A2
Table Top Frame (with glass removed)
B
Table Legs
C
Screws
D
Washers
E
Screw Covers
F
Hex Key
G
Touch-up Paint
Summer Silhouette
Hardware & Parts List
Description
1/4"*20
φ6.5*1.0
1/4"
! KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE !
Glass-Top Dining Table
TM
Model # 12255-011
Qty
1
4
24
24
24
1
1
