Aeon Labs AEO MULTISENS Quick Start Manual

Z-wave motion sensor, temperature sensor, humidity sensor and lightness sensor in one package
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
AEO_MULTISENS
Z-Wave Multisensor
Firmware Version : 1.18
Quick Start
S
This device is a Z-Wave Sensor. Single click the little button behind the battery cover to include or
exclude the device. Clicking the little button behind the battery cover will wake up the device and keep it
awake.
Please refer to the chapters below for detailed information about all aspects of the products usage.

Product description

The Aeon Labs Multisensor is a USB or battery-powered Z-Wave motion sensor, temperature sensor,
humidity sensor and lightness sensor in one package. The sensor will send radio signals up to 6 associated
Z-Wave devices within its own Z-Wave network when the sensor detects IR changes in front of its viewing
window. The Aeon Labs Multisensor complies with the IP43 standard so it can be used outdoors. By
adjusting the sensitivity of the sensor you can avoid the triggering due to small animals like dogs or cats.
The Aeon Labs Multi Sensor is delivered with a swivelling Back-Mount Arm for wall mount and a Back-
Mount Plate for ceiling mount.

Installation Guidelines

1. Release the Multisensor from the mounting by rotating it counterclockwise (sign: "Lock"/ "Unlock")
2. Put the 4 AAA batteries in the battery compartment.
3. The sensor can be mounted as follows:
(a) For wall mount use the screws with the swivelling Back-Mount Arm. Further fix the sensor with Back-
Mount Plate like shown in the picture.
(c) 2016 Z-Wave Europe GmbH, Antonstr. 3, 09337 Hohenstein-Ernstthal, Germany, All rights reserved, www.zwaveeurope.com - pp 1
