- Page 1 Installation Manual Crystalline module WSP and WST series WINAICO is a trademark of Win Win Precision Technology Co., Ltd. SIM2020-01(EN) www.winaico.com...
-
Page 2: Table Of Contents
WINAICO USA ..............................15 WINAICO Japan KK .............................. 15 This document applies to the WINAICO WSP and WST series and takes the place of all previous versions of the installation and mounting instructions for these modules. No responsibility is accepted for the correctness of this information. We reserve the right to technical changes. The documentation in place at the time the module was manufactured applies when undertaking installation, mounting and maintenance work. -
Page 3: Introduction
This manual is intended for qualified solar designers and installers to assist in the correct installation, operation and maintenance of WINAICO’s WSP and WST series solar panels. WINAICO solar panels should only be installed by qualified professionals authorised to carry out such work by their relevant local jurisdiction. Unqualified people should be kept a safe distance away. -
Page 4: Product Description
Max. Test Load (-)* 3,600 Pa 3,600 Pa Test and design load in accordance with IEC 61215:2016 version, depending on mounting options (please refer to section 6.1). WINAICO is a trademark of Win Win Precision Technology Co., Ltd. SIM2002-01(EN) www.winaico.com... - Page 5 WSP-MX 6X10 WSP-P6 / WSP-M6 6X10 WST-P6 / WST-M6 6X10 WINAICO is a trademark of Win Win Precision Technology Co., Ltd. SIM2002-01(EN) www.winaico.com...
-
Page 6: Warning Notices And Handling Instructions
Be sure to carefully follow the inverter manufacturer’s installation instructions! WINAICO modules are designed to meet the requirements for the IEC 61215, IEC 61730 and UL 1703 standards for operation in a temperate climate (the module operating temperatures are between -40 °C and +85 °C). Hazardous voltages (IEC 61730: higher than 50V DC;... -
Page 7: Module Handling
WINAICO Pallets can be stacked once on top for storage. Do not stack more than two pallets high • Leave modules in packaging until they are ready for install WINAICO is a trademark of Win Win Precision Technology Co., Ltd. SIM2002-01(EN) www.winaico.com... -
Page 8: Unpacking
• Orientation The performance of WINAICO Panels is dependent on the available solar resource, as well as their positioning in relation to the movement of the sun. Optimal panel tilting will be determined by the installation location, local siting restriction, and the load profile or desired generation profile. Your local WINAICO office can assist with optimum system design. -
Page 9: Mounting And Installation
The installation of on-roof systems can affect the fire safety of a building; improper installations can be a fire hazard. In the case of on-roof applications, the WINAICO modules must be mounted above a fire-resistant surface. The module is “non-explosion-protected equipment”. The use of improper installation methods and/or defective parts may result in the unexpected occurrence of an electrical arc during operation. -
Page 10: 6.1 Mechanical Module Mounting
6.1 Mechanical module mounting WINAICO modules are suitable for both vertical and horizontal installation methods due to their high degree of stability. The modules must be clamped in place at a minimum of 4 points. The modules are always installed with the junction box pointing upwards, such that the junction box is located on the rear side of the module in the upper section. - Page 11 Design Load Front(+) 1600Pa (=Test load/1.5) Rear(-) 2400Pa (=Test load/1.5) Rear(-) 1600Pa Examples of correct mounting methods: clamps can be used only at the specified clamping area WINAICO is a trademark of Win Win Precision Technology Co., Ltd. SIM2002-01(EN) www.winaico.com...
-
Page 12: Maximum Mechanical Load
WINAICO recommends installers should use certified solar cables (EN 50618: 2014) for direct current (DC) wiring in PV systems. The minimum wire size should be 12 AWG. -
Page 13: Cables And Connectors
WINAICO recommends the DC fuse should be used in each module string, in order to protect the solar modules in the event of a malfunction (e.g. an inverter defect). The fuses must be configured according to the maximum series fuse rating, which is quoted in the data sheets pertaining to the respective modules. -
Page 14: Safety Precautions
If an external lightning protection system is already provided or planned for the building, the photovoltaic system must be integrated into the system to protect against direct lightning strikes. The grounding hole is marked on the module frame. WINAICO is a trademark of Win Win Precision Technology Co., Ltd. SIM2002-01(EN) www.winaico.com... - Page 15 Please observe the national standards when grounding. If national standards do not require grounding, WINAICO still recommends all PV module frames to be grounded to ensure the voltage between the exposed metal parts (ex. frame) and earth ground is zero in all circumstances.
-
Page 16: Cleaning And Maintenance
As compliance with this user information and the conditions and methods for the installation, operation, use and maintenance of the modules from WINAICO cannot be checked or monitored, WINAICO shall assume no liability for damages resulting from improper use, faulty installation, operation, use or maintenance. -
Page 17: Contacts
Contacts If you have any questions, our WINAICO Team is available to assist you at all times: Taiwan Headquarters Win Win Precision Technology Co., Ltd. 4F., No.180, Sec. 2, Gongdao 5th Rd., East, Dist. Hsinchu City 300, Taiwan info@w-win.com.tw WINAICO Deutschland GmbH Industriestraße 68, 97993 Creglingen...
