- Page 1 User Manual 4K HDMI 2.0 Extender KVM 300ft/100m HDMI 4K@60Hz HDR EDID and RS232 EZ-EX70H2-KVM...
- Page 2 EZCOO, it’s easy, just cool! OVERVIEW HDMI2.0 Extender KVM EZ-EX70H2-KVM supports uncompressed HDMI 2.0 4K@60Hz , HDR, HDCP2.2; Supports bi-directional PoE,, bi-directional RS232,USB2.0 and EDID management, CEC pass through. It provides distribution of uncompressed 3840 x 2160@60Hz video,up to 100m/300ft over a single Cat6a/7 cable.
-
Page 3: Specifications
Supports Blue-Ray 24/50/60fs/HD-DVD/xvYCC Supports HDMI signal re-timing, never lose quality Supports bi-directional PoE, one power adapter powers on TX and RX; Either TX powers on RX, or RX powers on TX . Supports bi-directional RS232, easy to connect to control system. ... -
Page 4: Installation
8) Input/Output DDC signal: 5Volts p-p (TTL) 12) Max working current: 500mA 13) Power adapter format: Input AC 100V-240V/ 50HZ,60HZ; Output: DC24V/0.7A 14) Operating Temperature range: -15 to +55 ℃ 15) Operating Humidity range: 5 to 90%RH (No Condensation) 16) Dimension (L x W x H): 130*94*20(mm) 17) Weight: 380g INSTALLATION 1. -
Page 6: Troubleshooting
TROUBLE SHOOTING 1. POWER: Make sure all devices are powered on. 2. INDICATOR: Check LED indicators of HDMI Extender Transmitter and Receiver are on. Please refer to below LED indicators description. 3. DEVICES: Make sure picture can be shown normally when connecting HDMI source to display devices directly. - Page 7 4. HDMI CABLE: Plug in and out HDMI 2.0 cable or change another HDMI cable. When transmit HDMI 4K@60Hz signal,HDMI 2.0 certificated cables is required. 5. NETWORK CABLE: 5-1 Please use Cat5e/6a/7 cable, don` t suggest use Cat5. 5-2 Make sure CatX cable is less than 300ft for 4K. 5-3 Make sure the two connectors of one CatX cable are same standard (EIA/TIA 568B).
-
Page 8: Packing List
PACKING LIST 1. HDMI Extender Transmitter x1 2. HDMI Extender Receiver x1 3. Power Adapter x1 4. USB A to B cable x1 5. Mounting Ear x2 6. HOOK&LOOP x2 7. Reusable Cable Tie x2 8. User Manual x1 NOTES Please use this machine based on below instructions to keep longer lifetime. - Page 9 EZCOO TECHNOLOGY INC. assumes no responsibility for any inaccuracies that may be contained in this document. EZCOO TECHNOLOGY INC. also makes no commitment to update or to keep current the information contained in this document. EZCOO TECHNOLOGY INC. reserves the right to make improvements to this document and/or product at any time and without notice.
