- Page 1 User Manual 4K HDMI 2.0 1X2 Extender 165ft/50m HDMI 4K@60Hz 4:4:4 8bit EDID,IR and RS232 EZ-EXSP12 EZCOO, it’s easy, just cool!
- Page 2 OVERVIEW UTP HDMI Extender EZ-EXSP12 supports HDMI 2.0 4K@60Hz 4:4:4 8bit, HDCP2.2; Supports PoE, bi-directional IR, bi-directional RS232 and EDID management,. It provides distribution 3 of 3840 x 2160@60Hz 4:4:4 video, Two UTP outputs,one HDMI local loop output and Two-way IR up to 50m/165ft over a single Cat6a/7 cable.
-
Page 3: Specifications
Supports PoE, one power adapter powers on TX and RX without the power supply,Supports bi-directional IR, either TV controls Blue-ray DVD, or DVD controls TV via IR remote; So easy to set up control system. Supports bi-directional RS232, easy to connect to control system. ... - Page 4 8) Input/Output DDC signal: 5Volts p-p (TTL) 10) Max working current: 1.5A 13) Power adapter format: Input AC 100V-240V/ 50HZ,60HZ; Output: DC12V/2A 14) Operating Temperature range: -15 to +55 ℃ 15) Operating Humidity range: 5 to 90%RH (No Condensation) 16) Dimension (L x W x H): TX:130*94*20(mm);RX:83*58*22(mm) 17) Weight: 400g Panel...
-
Page 6: Installation
INSTALLATION 1. Connect HDMI cable from HDMI source devices to HDMI1X2 Extender input. 2. Connect network/Ethernet cable from UTP out (Transmitter) to UTP input (Receiver). 3. Connect HDMI cable from HDMI output (Receiver) to HDMI input on your display. - Page 8 EDID SETTING EDID switch on the front panel of transmitter EDID SETTING 4K7.1 4K@30Hz_4:3:3_7.1CHz_3D 4K5.1 4K@60Hz_4:4:4_5.1CHz_3D COPY LEARNING EDID FROM HDMI OUT...
-
Page 9: Troubleshooting
HDCP SETTING Test mode Strip out HDCP(Default) Normal mode HDCP1.4/2.2 pass through Scaler 1080P Down scaling from 4K to1080P TROUBLE SHOOTING 1. POWER: Make sure all devices are powered on. 2. Make DVD PLAYER 24P/24Hz ON. 3. DEVICES: Make sure picture can be shown normally when connecting HDMI source to display devices directly. - Page 10 certificated cables is required. 5. NETWORK CABLE: 5-1 Please use Cat5e/6a/7 cable, don` t suggest use Cat5. 5-2 Make sure CatX cable is less than 165ft. 5-3 Make sure the two connectors of one CatX cable are same standard (EIA/TIA 568B). 6.
-
Page 11: Packing List
PACKING LIST 1. HDMI1X2 Extender Transmitter x1 2. HDMI1X2 Extender Receiver x2 3. Power Adapter x1 4. IR Emitter x1 5. IR Receiver x1 6. Mounting Ear x2 7. HOOK&LOOP x2 8. Reusable Cable Tie x2 9. User Manual x1 CONTACTS When you need any technical assistance, please send e-mail to ezcoousa@easycoolav.com, support@easycoolav.com... - Page 12 EZCOO TECHNOLOGY INC. assumes no responsibility for any inaccuracies that may be contained in this document. EZCOO TECHNOLOGY INC. also makes no commitment to update or to keep current the information contained in this document. EZCOO TECHNOLOGY INC. reserves...
- Page 13 the right to make improvements to this document and/or product at any time and without notice.
