6. Connection Diagram

Sound source with
Smart Phone Smart Tablet
Windows PC iMAC
BT Connect
7. 4STREAM APP
7.1 4Stream App Download
Download the 4 Stream application from App Store for iOS based devices and from Google Play Store for Android based devices.
The application supports English, Spanish, French, German, Italian, Portuguese, Korean, Simplified Chinese, Traditional Chinese and
Japanese.
4STREAM
11
Active Subwoofer
Audio RCA output with RCA input
Sound source with
Digital Audio
Optical output
Ethernet RJ 45
connect to network
Router
Internet
to Sound System to Sound System
with Digital Audio
with Audio RCA input
Coax/Optical input
Connect to USB
pen drive
Smart Phone Smart Tablet
Windows PC iMAC
Wi-Fi Connect
Wi-Fi
DC input
AC/DC adapter
