Page 4
— to ensure optimum performance. Telephone 1300 11 4357 Again, thank you for choosing an Solt appliance and we look forward to being — of service to you. Email support@residentia.group...
Page 5
Safety Warnings IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE Read this manual thoroughly before first use, even if you are familiar with this type of product. The safety precautions enclosed herein reduce the risk of fire, electric shock and injury when correctly adhered to.
Page 6
User Manual Safety Warnings (Continued) General Safety Instructions Cont. • Earthing: This appliance should be properly earthed for your safety. The power cord of this WARNING • Do not use mechanical devices appliance is equipped with a three-prong plug or other means to accelerate the defrosting for use in standard wall outlets to minimise the process, other than those recommended by the possibility of electrical shock.
Page 7
Installation Cleaning and Maintenance Heavy: This appliance is heavy, take care when Disconnect: Unplug the appliance before cleaning moving it. To avoid back or other injury, consider a or servicing. Failure to do so can result in electric two person lift or mechanical aid when installing it.
Page 8
User Manual Product Overview Your Refrigerator Key: 1. Temperature control panel 7. Top hinge assembly 2. Glass shelves (×2) 8. Door trays (various) 3. Humidity control 9. Large freezer drawer 4. Fruit & vegetables crisper drawer 10. Freezer drawer 5. Flex-zone lower drawer 11.
Page 9
2 Proper use of refriger 2 1 P lacement solt.house Getting Started Unpacking • Packaging materials: This appliance has been packaged to protect it against transportation damage. Remove all packaging materials from around and inside the appliance and keep the original packaging carton and materials in a safe place.
Page 10
User Manual Installation (Continued) Installation Cont. Electrical connection WARNING • It must be possible to disconnect the appliance from the mains power supply; the plug must therefore be easily accessible after installation. • Before plugging in your fridge, let it stand upright for at least 2 hours. This will allow the refrigerant gases to settle into the compressor and reduce the possibility of a malfunction in the cooling system.
Page 11
(The picture above is only for reference.The actual configuration will depend on the phys (The picture above is only for reference.The actual configuration will depend on the or statement by the distributor) or statement by the distributor) cture above is only for reference.The actual configuration will depend on the physical product...
Page 12
User Manual 1. Please power off this appliance before conduct this operation. Remove all food from door shelves. 1. Please power off this appliance before conduct this operation. Remove all food from door shelves. 2. Remove the upper left hinge cover decorative cover, upper right hinge cover and upper right hinge; 2.
Page 13
Reversing the Door Cont. 4. Changing the refrigerator door: 5. Change the refrigerator door: Remove the cover plate of the upper end cover of the refrigeration door and the left decorative cover Remove the cover plate of the upper end cover of the refrigeration door and the left decorative cover.
Page 14
cover hat User Manual Installation (Continued) Stopper Reversing the Door Cont. 7. Install the reversed freezer door on the lower hinge, then install the middle hinge and cover the hinge hole 7. Install the replaced freezing door on the lower hinge, then install the middle hinge and cover the decorative cover.
Page 15
Using Your Refrigerator Fridge Compartment • The fridge compartment is suitable for storage of a variety of fruits, vegetabls, beverages and other foods to be consumed in short term. • Ensure that hot food has cooled down to room temperature before putting it into the fridge.
Page 16
User Manual 6) Freezer temperature adjustment paddle It is located at the lower left corner of the refrigerator, and the factory position of the paddle is on the right. Using Your Refrigerator (Continued) If the paddle moves to the left, the temperature of the freezer compartment will increase, and if the paddle moves to the right, the temperature of the freezer compartment will decrease.
Page 17
Usage Tips • Do not store food uncovered in the fridge. Always use good quality, fridge-proof packaging to maintain food quality. Remove air from packages of solid food and seal bags tightly before freezing. • Keep portions small to ensure they are frozen (and subsequently defrosted) rapidly.
Page 18
User Manual Maintenance and Cleaning Cleaning WARNING Before cleaning the appliance, make sure it is switched off and disconnected from the power supply. Failure to do so can result in electric shock or injury. • Dust behind the refrigerator and on the ground shall be timely cleaned to improve the cooling effect and energy saving.
Page 19
Contact our after sales support on 1300 11 43 57 for advice. Our after sales support centre stocks a selection of spare parts for the Solt 325L Bottom Mount Refrigerator. To enquire about purchasing a part, call us on 1300 11 43 57 or email...
Page 20
User Manual FAQs and Troubleshooting Problem Possible Cause Possible Solution The appliance • The appliance is not plugged in. • Plug in the appliance. does not • The appliance is turned off. • Turn on power point. operate. • The circuit breaker tripped or a •...
Page 21
Surface • Condensation may appear on the • Wipe away the condensation with a condensation exterior surface or door seals due to clean towel. high ambient temperatures. Abnormal • The compressor may buzz during • This is normal. sounds operation.
Page 23
Purchase Details For your records, please record details of your purchase The serial number can be found at the rear below and staple your receipt on this page. of your appliance. STORE DETAILS STORE NAME ADDRESS TELEPHONE PURCHASE DATE PRODUCT DETAILS MODEL NO.
Page 24
User Manual Warranty Information WARRANTY TERMS AND CONDITIONS IN THIS WARRANTY REFRIGERATION APPLIANCES ‘acceptable quality’ as referred to in clause 10 of this warranty has the same meaning referred to in This document sets out the terms and conditions of the the ACL;...
Page 25
You will bear the cost of transportation, travel and For Appliances and services provided by Residentia delivery of the Appliance to and from Residentia Group in Australia, the Appliances come with a Group or its ASR. If you reside outside of the service...
Page 26
An initiative by Residentia Group T. 1300 11 4357 E. support@residentiagroup.com.au www.solt.house...
