Summary of Contents for Solt GGSBF91DS
- Page 1 MODEL GGSBF91DS V1.0 0723 User Manual 87L Bar Fridge...
- Page 2 Telephone appliance to ensure optimum performance. 1300 11 4357 — Again, thank you for choosing an Solt appliance and we look forward to being Email of service to you. support@residentia.group Kind Regards,...
-
Page 3: Table Of Contents
Maintenance Troubleshooting Tips for Energy Saving Disposal Warranty Solt recommends the use of original spare parts. Customer When contacting our customer service team on 1300 11 4357, Care please ensure that you have the following information at hand (which can be found on your appliances’ rating plate). -
Page 4: Safety Warnings
1. SAFETY WARNINGS 1. Safety Warnings 1) WARNING―Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. 2) WARNING―Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. 3) WARNING―Do not damage the refrigerant circuit. 4) WARNING―Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer. -
Page 5: Installation Instructions
2. Installation Instructions 2.1 Location When selecting a position for your unit you should make sure the floor is flat and firm, and the room is well ventilated. Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase the electrical consumption. Extreme cold ambient temperatures may also cause the unit not to perform properly. This unit is not designed for use in a garage or outdoor installation. Do not drape the unit with any covering. When installing the unit, ensure that 20 cm of free space is left at both sides, 15 cm at the rear and 20 cm at the top of the unit. This will allow cold air to circulate around the wine cooler and improve the efficiency of the cooling process. The door can be opened to the right or the left, depending on what better suits the location. Please ensure there is adequate space for the door to fully open. - Page 6 4) Remove the plastic cover from door hinge first.Then unscrew the two screws from top bracket and replace on the other side. 5) To install the bracket on the left side of the appliance, screw the two screws through the bracket and into the top of the appliance.Slide the door back on to the top hinge.Ensure the door is face up.Replace the plastic cover on the top bracket by pressing down until it clicks into position. 6) Screw the bottom hinge into place on the new side. Replace the foot on the other side. 7) Check that the door is aligned horizontally and vertically and that the seals are closed on all sides before finally tightening the bottom hinge. Readjust the leveling feet. Door Space Requirements The unit's door must be able to open fully as shown. W×D≥800mm×780mm Levelling the Unit To do this adjust the two levelling feet at the front of the unit. If the unit is not level, the door and magnetic seal alignments will not be covered properly.
- Page 7 Cleaning Before Use Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm water using a 'Wrung-out' sponge or cloth. Wash the shelves and salad bin in warm soapy water and dry completely before replacing in the unit. Clean the exterior of the unit with a damp cloth. If you require more information refer to the Cleaning section. 2.6 Before Using Your Unit Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is working properly and to allow it time to fall to the correct temperature. Your unit should not be overfilled. ◆ Before Plugging in You must check that you have a socket which is compatible with the plug supplied with the unit. ◆ Before Turning On! Do not turn on until two hours after moving the unit. The coolant fluid needs time to settle. 2.7 Interior Accessories Various glass or plastic storage shelves are included with your appliance - different models have different combinations.
-
Page 8: Product Overview
3. Product Overview emperat re control ott le rack Glass shelves Veget able and fruit crisper *All images in this instruction manual are for indication only; please refer to your individual unit for details. 4. Operation 4. OPERATION 4.1 Adjusting the Temperature When using the refrigerator-freezer for the first time or after defrosting, turn the temperature control to set “MAX” for at least two hours before introducing the food to be stored. All frozen food products you purchase should be placed in the freezer compartment as soon as possible to avoid the frozen food from defrosting. In Winter or low temperature surrounded condition, please switch the temperature controller to large settings, like:MAX. -
Page 9: Cleaning
◆ To prevent cold air escaping from the unit, try to limit the number of times you open the door. We recommend that you only open the door when you need to put food in or take food out. 5. Cleaning 5. CLEANING Defrosting Frost may accumulate on the inner rear surface of the appliance which will automatically defrost during the of cycle of the compressor. Water is channelled via the drain hole to the collection tray above the compressor where it will evaporate. Please ensure the drain hole is checked and cleaned on a regular basis so water can exit the storage compartment. -
Page 10: Troubleshooting
technician. 6.4 Switching Of for Long Periods of Time When the unit is not in use for a long period of time, disconnect it from the mains supply, empty all food and clean the appliance, leaving the door ajar to prevent unpleasant smells. 7. Troubleshooting 7. Trouble shooting The following simple issues can be handled by the user. Please call the after-sale service department if the issues are not settled. Whether the freezer is plugged and connected to power; Inoperation Low voltage; Failure power or tripping circuit Odorous foods should closely wrapped; Odor Whether foods are rotten; Whether the interior shall be cleaned. It is normal that refrigerator operates for longer time in summer when the ambient temperature is higher; Long-term operation of Do not put too much food in the freezer at one time; compressor Do not put foods until they are cooled; Frequent opening of refrigerator door. Illuminating light does not Whether the refrigerator is connected to power, shine whether the illuminating light is damaged. The freezer door is stuck by food packages; The refrigerator door can not Too much food; be properly closed. Tilt refrigerator. Whether the food is leveled, whether the refrigerator is Loud noises balanced; Whether the refrigerator parts are properly placed. 7.1 Warm tips: ◆The refrigerator enclosure may emit heat during operation specially in summer, this is caused by the radiation of the condenser, and it is a normal phenomenon. -
Page 11: Disposal
behind the appliance). In normal temperature conditions, please arrange the thermostat at the middle setting. Before loading the appliance with packages of fresh food, make sure they are cooled to ambient temperature. Ice and frost layer increase energy consumption, so clean the appliance as soon as the layer is 3-5 mm thick. ◆ The appliance should be located in the coolest area of the room, away from heat producing appliances or heating ducts, and out of the direct sunlight. ◆ Let hot foods cool to room temperature before placing in the appliance. Overloading the appliance forces the compressor to run longer. Foods that freeze too slowly may lose quality, or spoil. ◆ Be sure to wrap foods properly, and wipe containers dry before placing them in the appliance. This cuts down on frost build-up inside the appliance. ◆ Appliance storage bin should not be lined with aluminum foil, wax paper, or paper toweling. Liners interfere with cold air circulation, making the appliance less efficient. ◆ Organize and label food to reduce door openings and extended searches. Remove as many items as needed at one time, and close the door as soon as possible. 9. - Page 12 This page is intentionally left blank...
- Page 13 This page is intentionally left blank...
-
Page 14: Warranty
Warranty Information WARRANTY TERMS AND CONDITIONS IN THIS WARRANTY REFRIGERATION APPLIANCES ‘acceptable quality’ as referred to in clause 10 of this warranty has the same meaning referred to in This document sets out the terms and conditions of the the ACL; product warranties for Residentia Group Appliances. -
Page 15: Contact Service
You will bear the cost of transportation, travel and For Appliances and services provided by Residentia delivery of the Appliance to and from Residentia Group Group in Australia, the Appliances come with a or its ASR. If you reside outside of the service area, you guarantee by Residentia Group that cannot be excluded will bear the cost of: under the Australian Consumer Law. - Page 16 An initiative by Residentia Group T. 1300 11 4357 E. support@residentiagroup.com.au www.solt.house...
