CRS518-16XS-2XQ-RM
CRS518-16XS-2XQ
Safety Warnings
Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents.
Ultimate disposal of this product should be handled according to all national laws and regulations.
The Installation of the equipment must comply with local and national electrical codes.
This unit is intended to be installed in the rackmount. Please read the mounting instructions carefully before beginning installation. Failure to use the
correct hardware or to follow the correct procedures could result in a hazardous situation for people and damage to the system.
This product is intended to be installed indoors. Keep this product away from water, fire, humidity, or hot environments.
Use only the power supply and accessories approved by the manufacturer, which can be found in the original packaging of this product.
Read the installation instructions before connecting the system to the power source.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your
own risk!
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.
It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling
requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik devices must be professionally installed.
Quick start
Connect with your computer to the device;
Download the configuration tool
Open the
Neighbors
tab and connect to the device using the MAC address;
admin
The user name:
To
update the device to the latest software version ownload the latest RouterOS software from
Choose
MIPSBE
packages, and save them to your computer;
Return to the WinBox and upload downloaded packages;
Restart the device.
Mounting
The device is designed to use indoors and it can be mounted in a rackmount enclosure using provided rack mounts, or it can be placed on the desktop.
Please attach rubber pegs on the bottom of the router if the desired placement is on the flat surface or use a Phillips screwdriver to attach rackmount ears
on both sides of the device if the designated use is for rackmount enclosure:
1.
Attach rack ears to both sides of the device and tighten four screws to secure them in place, as shown in the picture.
2.
Place the device in a rackmount enclosure and align with the holes so that the device fits conveniently.
https://mt.lv/winbox
;
, by default there is no password (or, for some models, check user and wireless passwords on the sticker);
d
https://mikrotik.com/download
;

Advertisement

loading
Need help?

Need help?

Do you have a question about the CRS518-16XS-2XQ-RM and is the answer not in the manual?

Questions and answers

Summary of Contents for MikroTik CRS518-16XS-2XQ-RM

  • Page 1 In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet. It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik devices must be professionally installed. Quick start Connect with your computer to the device;...
  • Page 2 Nominal current 12.5 A. AC input range 100-240 V. Max power consumption (without attachments) 45 W. Max power consumption 77 W. Expansion slots and ports Product code CRS518-16XS-2XQ-RM. Switch chip model 98DX8525. CPU QCA9531 650 MHz. CPU architecture MIPSBE. CPU core count 1.
  • Page 3 Accessories Package includes the following accessories that come with the device: Please visit the wiki pages for the MikroTik SFP module compatibility table: https://wiki.mikrotik.com/wiki/MikroTik_SFP_module_compatibility_table Safety Notice Electric shock hazard. This equipment is to be serviced by trained personnel only.
  • Page 4 Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
