P H A N T A S M
K I T E
6 3 3

Advertisement

loading
Need help?

Need help?

Do you have a question about the PHANTASM KITE 633 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Slingshot PHANTASM KITE 633

Summary of Contents for Slingshot PHANTASM KITE 633

  • Page 1 P H A N T A S M K I T E 6 3 3...
  • Page 2 PHANTASM KITE 633 PACKAGE After two years of meticulous and extensive research and development, we are proud to introduce the ALL NEW Phantasm 633. The Phantasm 633 is a high-performance carbon freeride foil with tons of versatility in a lightweight premium carbon construction.
  • Page 3 COMPLETE FOIL SETUP PFI 633 FRONT WING NEOPRENE COVER SKU: 121237006 PHANTASM 400 STABILIZER T30 TORX WRENCH NEOPRENE COVER *SKU: 121237008 SKU: 121237007 PHANTASM 633 FOIL PACKAGE CARRING CASE *COMPLETE HARDWARE SKU: 121237005 PACKAGE SKU: 121237008 MAST 92 cm SKU: 121237001 710 FUSELAGE SKU: 121237002 BARREL NUT M6...
  • Page 4 FOIL ASSEMBLY Coat all bolt hardware with Lanolin oil or a marine-grade grease and wrap with Teflon tape before assembling your foil. (see maintenance section for details) Connect the front wing to the fuselage using the M6x37mm flathead screw for the forward hole, the M6x40mm screw for the center hole and the M6x30mm screw for the third hole.
  • Page 5 Note: Mounting hardware comes packaged with Slingshot foil boards, and is not included in the foil package. Carefully place your foil over the mounting track so the front hole pattern in the pedestal line up with the mounting hardware.

  • Page 6: Maintenance

    SAFETY MAINTENANCE Foiling comes with a unique set of challenges, risks and It is imperative to clean and lubricate your foil regularly, dangers. Know your limits, know your gear, know the especially after use in salt water. This is true for all of your conditions and use extra caution to keep yourselves gear, but especially for your foil.
  • Page 7 LUBRICATE HARDWARE: In a clean, sand-free area, carefully coat all bolt hardware, bolt holes and ALL connection points with a layer of Lanolin oil or marine-grade grease. Coat anywhere that parts touch each other to prevent them from corroding and fusing together. Don’t forget the inside of your fuselage to mast slot.
  • Page 9 WW W. S L I NGS H OTSP O RTS .CO M CON TACT: I N FO @ S LI N GS HOTSP O RTS .CO M R I D E R S E RVI C E IN T HE U S: 87 7.775 .4 8 32 INT E RN AT I ON A L PHO N E: 50 9.427.4950...
