Summary of Contents for Slingshot Machine
- Page 1 USER MANUAL 2005...
-
Page 2: Table Of Contents
Machine USER MANUAL TABLE OF CONTENTS Parts List........2 Inflation .........3 Machine Bar .........4 Clip & Ride reboot......5 Machine setup.......6 Launching........7 Relaunch........8-9 Safety 10-11 ............. Performance.........12-15 Tuning & Maintenance....16-17 Warranty / Disclaimer....18-20 CONTACT assistance, please email us or visit our website: http://www.sskiteboarding.com... - Page 3 With the use of Oneline, riders have all the benefits of the most advanced safety system in addition to the latest performance features that allow the rider to “sheet” and “trim” the Machine from the bar. Having the ability to adjust the shape and angle of attack of the kite on-the-fly results in added power for early planing, loftier...
-
Page 4: Inflation
INFLATION STEPS 1. Close the OUT valve and secure with Velcro straps. 2. Make sure valve clip for each strut is open. 3. Clip the pump leash to the leash loop on the leading edge (LE) of the kite. 4. Insert pump nozzle into IN valve and secure with a slight twist. 5. -
Page 5: Parts List
Machine MACHINE BAR PARTS LIST (A) Quick Release Surefire (J) Wave Grenade pin Bungee Leash (K) Trim cleat-Oneline (B) Lock-n-Load (L) Trim handle (C) Safety release knob (M) Oneline (D) Adjustable stopper ball (N) Removable Donkey Dick (E) Depower cleat... -
Page 6: Clip & Ride Reboot
Machine CLIP & RIDE REBOOT STEPS 1. Pull out some slack in the Oneline. 2. Loosen screw on Bell Housing and slide up the rope to expose the swivel. 3. Take the swivel end with the bend in it and insert it up into the loop in your chicken loop. -
Page 7: Machine Setup
Machine KITE SETUP ATTACHING THE ONELINE BAR AND LINES TO KITE STEPS 1. Pump up your kite and lay out the bar and lines upwind of the kite with leading edge facing you. 2. Lay out the Oneline kite pigtail behind the kite (laying away from your bar). -
Page 8: Launching
LAUNCHING STEPS 1. Find a wide open area with unobstructed steady wind. Make sure there are no rocks, trees, fences, cars, power lines or people downwind of you or in your wind window Have your launching partner walk your kite to the edge of the wind window and have them turn the kite on its side and hold the leading edge facing towards the wind. -
Page 9: Relaunch
Machine RELAUNCH STEPS 1. When your kite crashes leading edge down, let the kite drift directly downwind of you and make sure all lines have equal tension. 2. Pull your Oneline in using a hand over hand technique to bring the leading edge towards you until your kite is lying on its back. - Page 10 RELAUNCH STEPS 4. Continue working your kite to the edge of the wind window by applying pressure to the appropriate steering lines. Do a final check to make sure all lines are clear of body parts and that there are no lines caught or tangled on your bar. If at any time you don’t feel comfortable, simply cleat off your Oneline with at least two feet pulled in to prevent your kite from launching.
-
Page 11: Safety
Machine SAFETY GETTING STARTED Always begin your session by making sure your Oneline glides freely through the center of the bar by pulling in the Oneline trim and releasing it. The best time to do this is when someone is holding your kite in the position where you are ready to launch and all five lines are taught. -
Page 12: Safety
SAFETY MACHINE RELAUNCH SAFETY After letting go of your bar: In the event you let go of your bar, the Oneline will immediately kill all power to the kite. To retrieve the bar, use a hand over hand technique to pull yourself to the bar. -
Page 13: Performance
Machine PERFORMANCE ONELINE MODES AND FUNCTIONS Oneline terms Depower Decreasing the overall power of the kite by locking off the chicken loop rope Sheeting (Throw) Adjusting the overall power of the kite by pushing the bar in or out. Trim Adjusting the tension of the Oneline by either pulling in and cleating the Oneline (Trimmed in) or unlocking the Oneline to disengage tension (Trimmed out). - Page 14 PERFORMANCE MODES All modes begin with the bar in the middle to lower half of chicken loop line with the rider hooked into chicken loop. ** Refer to the performance characteristics on page 15. Mode 1 - Oneline is trimmed in (Oneline engaged approximately 2-8 inches de- pending on kite size and wind range).
- Page 15 CONTINUED MODES Mode 2-bar sheeted out Mode 3 - Oneline is trimmed in (Oneline engaged approximately 2-8 inches depending on kite size and wind range). The depower line is pulled in (depower engaged). The bar is sheeted either all the way in or all the way out. Advantage: Similar performance to mode 2 with the benefit of depowering the kite in higher wind conditions.
-
Page 16: Performance
CONTINUED PERFORMANCE CHARACTERISTICS Stock Bar Mode Performs like standard four line kite with increased safety, kite stability and relaunch capabilities. Mode 1 Additional low end power by opening canopy shape for increased projected area. Kite flies further in the edge of the wind window, increasing upwind performance. -
Page 17: Tuning & Maintenance
Oneline trim line is pulled in. Oneline should have no twists around center lines. Oneline setup instructions are written for stock Slingshot kites and bar setup with original pigtails. If you take off the safety pigtails from the end of your flying lines, Oneline length will need adjusting. -
Page 18: Tuning & Maintenance
5. Continue folding until you reach the center of the kite. 6. Repeat steps 1-5 on other side of kite. 7. Stuff into bag trailing edge first. Important- Once the Machine is folded, do not attempt to bend kite or batten in half. P 11 P 17... -
Page 19: Warranty / Disclaimer
GUIDELINES General Warranty Policy applying to customers located within U.S. If a product is found defective by Slingshot, in its sole discretion, Slingshot’s only responsibility shall be limited to credit, repair or replacement of the defective product. Slingshot will not be responsible for any costs, losses or damages incurred as a result of loss or use of product. - Page 20 Guidelines. STEP TWO Bring the product to the store where it was purchased OR Call Slingshot for a Return Authorization (RMA) Number OR email warranty@sskiteboarding.com to obtain an RMA number. Please note that warranty claims will not be processed without an RMA number.
- Page 21 To waive any and all claims that you have or may in the future have against Slingshot Sports LLC resulting from use of this product and any of its components.To release Slingshot Sports LLC from any and all liability for any...
- Page 22 MACHINE MACHINE BAR QUICK FIX The wall thickness on the piece of the latex is incorrect. Cut this off. The existing tubing is the correct one. Slide latex into position and push bar stop into place.
- Page 23 65435 SR 14, WHITE SALMON, WA 98672 509-493-3979...
