- Page 1 DABS1010 Belt sander USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. GENERAL SAFETY RULES ........................3 2. SPECIFIC SAFETY RULES ........................4 3. FEATURES ............................... 4 4. ASSEMBLY ............................... 5 5. OPERATION ............................. 6 6. MAINTENANCE ............................7 7. TECHNICAL SPECIFICATIONS ....................... 8 8. EXPLODED VIEW ..,..........................9 WARRANTY ............................... 11... -
Page 3: General Safety Rules
WARNING! Read and understand all instructions. Failure to follow all instructions listed below, may result in electric shock, re and/or serious personal injury. 1. GENERAL SAFETY RULES SAVE THESE INSTRUCTIONS Work area 1. Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents. 2. -
Page 4: Specific Safety Rules
4. Disconnect the plug from the power source before making any adjustment, changing accessories, or storing the tool. Such preventive safety measures can reduce the risk of starting the tool accidentally. 5. Store idle tools out of reach of children and other untrained persons. Tools are dangerous in the hands of untrained users. -
Page 5: Assembly
4. ASSEMBLY Fitting the dust collection bag This machine is tted with a dust extraction outlet and collection bag. We recommend that this facility is used at all times, as well as using an approved face mask. Fit the dust collection bag onto the dust extraction outlet (See 1 of Fig.2). -
Page 6: Operation
Centralizing the sanding belt Check that the sanding belt is running centrally before using. Centralizing the belt is necessary to stop the belt running off the rollers. Turn the machine with the belt facing the operator (See Fig.5). Start the sander and observe how the sanding belt is running. If the sanding belt is seen to move along the rollers in either direction, it will require centralizing before use. -
Page 7: Maintenance
Maneuver the sanding belt off the rollers. NOTE: The Sanding belt has directional arrows printed on the inside of the belt (See 1 of Fig.8) Fig. 8 Sanding belts come in different grades i.e. rough through to smooth. Select the grade according to the material operated on. -
Page 8: Technical Specifications
and excessive sparking seen through the ventilation slots. When the carbon brushes have worn down to approximately 4-5mm, they will require replacing. Caution! Make sure that the sander is isolated from the mains power supply before tting acces- sories, maintenance and adjustment if in doubt consult a quali ed electrician. Place the sander on a workbench and using a screwdriver remove the carbon brush housing cover (See 1 of Fig.10). - Page 10 (x1) 1. The belt cover (x1) 56. The rear wheel 2. Belt - 102×L031 (x1) (x1) 57. Bowl gasket ø21×ø10 3. The middle cover (x1) (x1) 58. Copper set of ø16×ø10×9 4. Cross slotted self tapping screw - ST4×14 (x12) (x1) 59.
-
Page 11: Warranty
WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 2 years for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed. - Page 12 Manufactured under license of Daewoo International Corporation, Korea...
